9.Technical Data
GENERAL
Enclosure
Operating temperature
Operating Altitude
Powder coated aluminum
-25~60℃, full power up to 40℃
2000m
Relative humidity 0 – 100% non condensing.
Environmental category Outdoor, wet locations
Protection degree IP65 (Electronics)
Pollution degree 3
Overvoltage category AC output :III, DC Input :II
Maximum backfeed
current to the array
0
Galvanic isolation NO
Safety class Class I metal enclosure with protective earth
Weight 43kg
Dimensions(W*H*D) 612 × 625 × 278mm
Connectors Weather resistant connectors
DC INPUT (Solar side)
Recommended
PV power range
Maximum input power
Nominal voltage
Operating voltage
Startup voltage
22kW
18kW – 25kW
16.5kW
14kW – 19kW
635Vdc
200Vdc – 1000 Vdc
> 250 Vdc
Start up power
40W
MPP tracker
Parallel inputs: 1 MPP tracker
Separate inputs: 2 MPP trackers
Absolute maximum voltage
1000V
RPI-M15A RPI-M20A
47
Technical Data
