6.3. Maintenance
Makesurethatthedeviceremainsuncoveredduringthecompleteoperatingtime.
Toavoidthatthecasingofthesolarinverterbecomestooheavilysoiled,itshouldbecleanedfrom
timetotime.
Userserviceablepartsarenotcontainedinthedevice.Undernocircumstancesthesolarinverter
shouldbeopened!
6.4 Installation
Youshouldemploythedeliveredmountingplateforproblem-freeinstallationofthesolarinverter.
Theattachmentonthewallshouldbeimplementedwithadequatescrews.Mountthewallbracket
sothatthesolarinverteronlyhastobesimplyattachedatalatertime.Afterthat,thedeviceistobe
boltedonsecurely.
Assemblyinstructions
1. Mountthemountingplatewithappropriatescrews(max.Ø6mm)intoatleastfourof
 theeightholestoxthewallbracketinplace.Youcanemploythemountingplateasa
 drilltemplateformarkingthepositionsfortheboreholes.
2. Asthesolarinverterweighs32kg,itshouldbeliftedoutofthetransportcratebyatleast
 twopersons.
3. Placethesolarinverterontothemountingplatewithatleasttwopersons.
4. Fastenthesuppliedmountingnutsandwashersonthethreadedboltintendedforsecu-
 ringthedevice.
5. Checkthesolarinverterforsecureseating.
319.5
150
320
200
6.5
12
Ø
12.5
90
38
12
410 ± 0.5
Mounting
plate
Lockingscrew
Lockingscrew
