9 Technical Data
Input (DC) Output (AC)
Max.recommendedPVpower 6000W Nominalpower 5000W
Nominalpower 5500W Max.power 5240W
Voltagerange 125...540V Nominalvoltage 230V
MPPrange 150...450V Voltagerange 196...264V
FullpowerMPPrange 150...450V Nominalcurrent 22.0A
Nominalcurrent 17.2A Max.current 27.2A
Max.current 36.6A Max.makingcurrent 30.0A
Max.faultcurrent 42.0A Nominalfrequency 50Hz
Max.ACrecovery
0Aviainternal
transformer
Frequencyrange 49.5...50.5Hz
Stand-bypower <0.2W
Tolerance,voltagedetecion 1.5%
Tolerance,frequencydetection 0.1%
Tolerance,DCdetectiononAC 3.0%
Tolerance,trippingtimes 1.0%
Generalspecication Mechanical design
Efciencymax. 95.6% Size WxLxD(mm)
EfciencyEU/California 94.6% 410x510x180
Operatingtemperaturerange -25...+60°C Weight 32.0kg
Storagetemperaturerange -25...+80°C Cooling Freeconvection
Humidity 0...98% ACconnector PhoenixVARIOCON
DCconnector 4TycoSolarlok
Communicationinterfaces 2HartingRJ45/RS485
Certication Norms
Protectionclass IP65 Anti-islandingprotection DINVDE0126-1-1
Safetyclass 1 EMI/EMC EN55022ClassB
Overloadcharacteristic
Currentlimiting;power
limiting
EN61000-4-2...
EN61000-4-6
Safety
EN60950-1;IEC62103;
DraftIEC62109-1/-2;
EN50178
EN61000-4-8
Congurabletripparameters Yes EN61000-3-2
Insulationmonitoring Yes EN61000-3-3
