7 Operating concept
7.1 The display
Thedeliveryofthesolarinverterisimplementedreadyforoperation.Nopresettingadjustmentsare
thereforenecessaryfortheuser.
Thedisplayonthedeviceindicatesdifferentinformation.Theenterkeysareusedfortheadjustment
ofthedeviceandforthecall-upofinformation.Theindicatedmeasuringdatacandeviatewitha
toleranceofupto5%.
ESC
(A) (B) (C) (D)
7.2 Navigation in the display
Lightingofthedisplay
ThroughpressingtheENTERkeyinautomaticoperation,thedisplaylightingisimplemented.Ifno
keyshouldbeactivatedwithin30seconds,thedisplaylightingautomaticallygoesout.Thesetup
menuenablesselectionbetweencontinuousorautomaticlighting.ThroughpressingtheENTER
key,thedisplaylightingisswitchedonagain.
Key(A),ESC: Toswitchfromthemenu
 itemstothemainmenuand
 toexiteachsub-menu.
Key(B)and(C):Forscrollingintheindividual
menuitemsand/orcarrying
outadjustmentsinthesetup
menu.
Key(D),ENTER: ENTERkeyforchanginginto
 themenulevelsandforinput
acknowledgementinthe
 setupmenu.
LEDStatus Operational state Explanation
green:<off>
red:<on/off>
yellow:<on/off>
Equipmentfault.
Internalorexternalfault
(interruptedfeed).
Seealsodisplaymessages!
green:<on/ashes>
red:<on>
yellow:<off>
Earthfault.
TheinsulationresistancebetweenPV(-)and/
orPV(+)islessthan550kOhms.
green:<off>
red:<on/off>
yellow:<on>
Generalerror
conidtion.
SolarInverterisnotconnectedtothegrid.
Nopowerisdelivered.
Seealsodisplaymessages!
green:<on/off>
red:<on/off>
yellow:<ashes>
Warningmessage.
Youcancarryonusingthesolarinverter.
Seealsodisplaymessages!
