Chapter 2 Introduction
7
z
z
Long Backup Model: UPS102N2002N0B0 (1kVA)/ UPS202N2002N0B0
(2kVA) / UPS302N2002N0B0 (3kVA):
SETUP
ON
OFF
1 2 3
4
5
6
7 8 9
No. Item Q’ty 1/ 2kVA 3kVA
1
UPS 1 PC
2
User Manual 1 PC
3
Terminal Copper *
1
3 PCS
4
Cable Tie (Type A) *
1
1
1 PC
5
Cable Tie (Type B) *
2
1 PC
6
Battery Wire 1 PC
7
Ring-type Thimble *
2
2 PCS
8
Joint *
2
2 PCS
9
Wire Mount *
2
1 PC
*
1
: The terminal copper (3 PCS) and cable tie (Type A: 1 PC) are used to
connect the UPS output terminals ( L, N,
) located at the rear of the 3kVA
UPS.
*
2
: If the provided battery wire (1 PC) is not long enough and you want to use
a longer battery wire (not provided), please use the provided joint (2 PCS),
ring-type thimble (2 PCS), cable tie (Type B: 1 PC) and wire mount (1 PC) to
join them together.
