Chapter 6 Optional Accessories | VFD-ED
6-19
Figure 6-14
Unit: mm
Input Reactors
Delta Part #
DR180AP070 See above.
Table 6-18
Terminal gauge: 4 mm
2
Tightening torque: 0.6–0.8 Nm
PE M8 x 23
Tightening torque: 6±0.3 Nm
