Chapter 5 Parameters_VFD-B Series
5-70
Revision 10/2005, BE13, SW V4.08
05 - 17
Time Duration of 1st Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 18
Time Duration of 2nd Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 19
Time Duration of 3rd Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 20
Time Duration of 4th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 21
Time Duration of 5th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 22
Time Duration of 6th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 23
Time Duration of 7th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 24
Time Duration of 8th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 25
Time Duration of 9th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 26
Time Duration of 10th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 27
Time Duration of 11th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 28
Time Duration of 12th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 29
Time Duration of 13th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 30
Time Duration of 14th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
05 - 31
Time Duration of 15th Step Speed Unit: 1 or 0.1sec (See Pr.05-32)
Settings 0.0 to 65500 Factory Setting: 0.0
Pr.05-17 to Pr.05-31 correspond to operation time of each step speed defined by Pr.05-00 to Pr.05-14. The
maximum setting of 65500 seconds will be displayed as “t6550x”. If display shows “t6550”, it means 6550
seconds.
If a parameter is set to “00” (0 sec), the corresponding step will be skipped. This is commonly used to reduce
the number of program steps.
05 - 32
Time Unit Settings
Factory Setting: 00
Settings 00 1 sec
01 0.1 sec
This parameter sets the time unit for Pr.05-17~Pr.05-31.
