Revision 10/2005, BE13, SW V4.08 5-1
Chapter 5 Parameters
The VFD-B parameters are divided into 12 groups by property for easy setting. In most applications, the user can
finish all parameter settings before start-up without the need for re-adjustment during operation.
The 12 groups are as follows:
Group 0: User Parameters
Group 1: Basic Parameters
Group 2: Operation Method Parameters
Group 3: Output Function Parameters
Group 4: Input Function Parameters
Group 5: Multi-Step Speed and PLC Parameters
Group 6: Protection Parameters
Group 7: Motor Parameters
Group 8: Special Parameters
Group 9: Communication Parameters
Group 10: PID Control Parameters
Group 11: Fan & Pump Control Parameters
