Delta VFD220B43A - Page 24

Chapter 2 Installation and Wiring_VFD-B Series
2-6
Revision 10/2005, BE13, SW V4.08
Frame B: VFD022B21A, VFD037B23A/43A/53A
11.3 [0.44]
6
.
5
[
0
.
2
6
]
2
2
.
0
[
0
.
8
7
]
(
2
X
)
2
8
.
0
[
1
.
1
0
]
(
2
X
)
R
3
.
2
5
[
R
0
.
13
]
6.5[0.26]
260.0[10.24]
UNIT : mm(inch)
135.0 [5.32]
160.2 [6.31]
244.3 [9.63]
150.0 [5.91]
