Delta VFD220B43A User Manual

Chapter 5 Parameters_VFD-B Series
Revision 10/2005, BE13, SW V4.08 5-11
Parameter Explanation Settings
Factory
Setting
Customer
a05-02 3
rd
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-03 4
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-04 5
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-05 6
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-06 7
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-07 8
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-08 9
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-09 10
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-10 11
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-11 12
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-12 13
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-13 14
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
a05-14 15
th
Step Speed Frequency 0.00 to 400.00 Hz 0.00
00: Disable PLC operation
01: Execute one program cycle
02: Continuously execute program cycles
03: Execute one program cycle step by step
05-15 PLC Mode
04: Continuously execute program cycles
step by step
00
05-16 PLC Forward/ Reverse Motion 00 to 32767 (00: FWD, 01: REV) 00
05-17 Time Duration of 1st Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-18 Time Duration of 2nd Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-19 Time Duration of 3rd Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-20 Time Duration of 4th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-21 Time Duration of 5th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-22 Time Duration of 6th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-23 Time Duration of 7th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-24 Time Duration of 8th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-25 Time Duration of 9th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-26 Time Duration of 10th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-27 Time Duration of 11th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-28 Time Duration of 12th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-29 Time Duration of 13th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-30 Time Duration of 14th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
05-31 Time Duration of 15th Step Speed 00 to 65500 sec or 00 to 6550.0 sec 00
00: 1 sec
05-32 Time Unit Settings
01: 0.1 sec
00
