Chapter 12 Description of Parameter SettingsMS300 (High Speed Model)
12-02-3
6: JOG operation (By KPC-CC01 or external control)
7: Acceleration / deceleration speed not allow
8: The 1
st
, 2
nd
acceleration / deceleration time selection
9: The 3
rd
, 4
th
acceleration / deceleration time selection
10: EF input (Pr. 07-20)
11: B.B input from external (Base Block)
12: Output stop
13: Cancel the setting of the auto acceleration / deceleration time
15: Rotating speed command from AVI
16: Rotating speed command from ACI
18: Forced to stop (Pr. 07-20)
19: Digital up command
20: Digital down command
22: Clear counter
23: Input the counter value (MI6)
24: FWD JOG command
25: REV JOG command
28: Emergency stop (EF1)
29: Signal confirmation for Y-connection
30: Signal confirmation for -connection
38: Disable write EEPROM function
40: Force coast to stop
41: HAND switch
42: AUTO switch
49: Drive enable
50: Master dEb input
51: Selection for PLC mode bit 0
52: Selection for PLC mode bit 1
53: Trigger CANopen quick stop
56: Local / Remote Selection
81: Zero point position signal input of simple positioning
83: Multi-motors (IM) selection bit 0
84: Multi-motors (IM) selection bit 1
 This parameter selects the functions for each multi-function terminal.
 When Pr. 02-00 = 0, multi-function options can be set by multi-function input terminal MI1, MI2.
 When Pr. 02-00 ≠ 0, specify the use of multi-function input terminals MI1, MI2 with reference to
the setting value of Pr. 02-00.
Example:
If Pr. 02-00 = 1: multi-function input terminal MI1 = FWD / STOP,
multi-function input terminal MI2 = REV / STOP.
If Pr. 02-00 = 2: multi-function input terminal MI1 = RUN / STOP,
multi-function input terminal MI2 = FWD / REV.
