Denlar D100 - Page 8

D1000 Installation and Service Manual 7
Home LAB-110073 Rev. 3
(
Cabinet Bottom
View)
Access Hole for 7”
Duct
PREPARING THE INSTALL LOCATION
Min
Max
D1030 24"
30"
D1036 30"
36"
Installation Heights
4”
5 7/8”
Standard
Bracket
NFPA101
Bracket
Cabinet Front
B
B
A
A
B
C
D
28 5/8”
1/16”
1/16”
10 5/16””
1 5/8”
Mounting Bracket for D1000-F/R
(non-NFPA101)
Note # 6
Mounting Bracket
D1000 MOUNTING BRACKET
A. Center Notches
B. Critical Mounting Points (must be secured to suds or
dry wall hangers)
C. Primary Access Point for connections to hood
(options/accessories)
a. Supply lines run inside of the wall.
D. Additional Mounting Points
7 3/16”
4
”
C
D
NFPA101 “F” & “R” Rev
Install
See Pages 10 & 11 for
details
