Denon AVR-1513 Service Manual

10
DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the reassembling, observe "Caution concerning disassembly and assembly!".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
FRONT PANEL ASSY
Refer to
"DISASSEMBLY
1. FRONT PANEL ASSY"
and
"EXPLODED VIEW"
FRONT PCB
(Ref. No. of EXPLODED VIEW : C1-1)
POWER KNOB PCB
(Ref. No. of EXPLODED VIEW : C1-2)
HEADPHONE PCB
(Ref. No. of EXPLODED VIEW : C1-3)
PORTABLE PCB
(Ref. No. of EXPLODED VIEW : C1-4)
USB PCB
(Ref. No. of EXPLODED VIEW : C1-5)
F-HDMI PCB
(Ref. No. of EXPLODED VIEW : C3-2)
RADIATOR ASSY
Refer to
"DISASSEMBLY
3. RADIATOR ASSY"
and
"EXPLODED VIEW"
MAIN PCB
(Ref. No. of EXPLODED VIEW : C2-1)
POWER PCB
Refer to
"DISASSEMBLY
4. POWER PCB"
and
"EXPLODED VIEW"
POWER PCB
(Ref. No. of EXPLODED VIEW : C4-1)
REGULATOR PCB
Refer to
"DISASSEMBLY
5. REGULATOR PCB"
and
"EXPLODED VIEW"
REGULATOR PCB
(Ref. No. of EXPLODED VIEW : C4-2)
TRANS POWER
Refer to
"DISASSEMBLY
6. TRANS POWER"
and
"EXPLODED VIEW"
TRANS POWER
(Ref. No. of EXPLODED VIEW : C6 )
DIGITAL PCB ASSY
Refer to
"DISASSEMBLY
2. DIGITAL PCB ASSY"
and
"EXPLODED VIEW"
DIGITAL PCB
(Ref. No. of EXPLODED VIEW : C3-1)
TUNER PCB
(Ref. No. of EXPLODED VIEW : C2-5)
TOP CABINET

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
