Denon AVR-1513 Service Manual

17
1. µcom/DSP/OSD Version display mode
1.1. Operationspecications
µcom/DSP/OSD version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the
X
button to turn on the power while pressing the "DIMMER" and "STATUS" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
1.2. Display Order
q
Model destination information →
w
Main-µcom version →
e
DSP version →
r
OSD version
Display State
q
Model destination information
AVR-1513 E3 model
A V R 1 5 1 3 E 3
AVR-1513 E2 model
A V R 1 5 1 3 E 2
AVR-1513 E1C model
A V R 1 5 1 3 E 1 C
w
Main-µcom version
M a i n : * * . * *
e
DSP version
D S P . * . * . *
r
OSD version
O S D : * * . * *
Cleared of mode:
Press the
X
button to turn the power off.
1.3. Error display
See the following table for each "Error information" display and its contents (status).
Condition - State
DSP NG When DSP boot, executing DSP reset makes to becomes error.
D S P E R R O R 0 1
DSP OK (No error display, version display only)
