Denon AVR-1513 Service Manual

114
Ref. No. Part No. Part Name Remarks Q'ty New
CAPACITORS GROUP
C1002 nsp CAP,MYLAR(100V/0.1uF/J) HCQI1H104JZT
C1003 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T
C1004 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1005 00MOA22706320 CAP,ELECT(63V/220uF) CCEA1JH221E
C1006 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C1009 nsp CAP,CHIP(2012,50V/0.1uF) CCUC1H104KC
C1010 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C1011 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1013,1014 nsp CAP,CHIP(1608,50V/100pF) CCUS1H101JA
C1015 nsp CAP,CHIP(1608,50V/330pF) CCUS1H331JA
C1016 nsp CAP,CHIP(1608,50V/1000pF) CCUS1H102KC
C1017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C1019 00D9430175108 CAP,ELECT(50V/10uF) CCEA1HH100T
C1020 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C1038 943134010670S CAP,ELECT(16V/47uF)-S CCEA1CKS470T
C1039 nsp CAP,CHIP(1608,50V/100pF) CCUS1H101JA
C1042 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T
C1043,1044 nsp CAP,CHIP(1608,50V/220pF) CCUS1H221JA
C1046,1047 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1054,1055 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1058-1060 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T
C1061,1062 nsp CAP,CHIP(1608,50V/330pF) CCUS1H331JA
C1063,1064 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1065 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1066 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1067 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1068 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1071,1072 nsp CAP,CHIP(1608,50V/220pF) CCUS1H221JA
C1073 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1076,1077 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C1081 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
C1410,1411 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C1424 nsp CAP, CHIP(1608, 25V/1uF) CCUS1E105ZF
OTHERS PARTS GROUP
BK101,102 nsp BRACKET,FIP CMD1A572
BK103 nsp PCB BRACKET CMD1A629
BN103 nsp WIRE ASS'Y CWB1B005050HC *
BN11A nsp WIRE ASS'Y CWB1B005080CC *
BN13A nsp WIRE ASS'Y CWB1B003080CC
CN101 nsp WAFER,FPC1.25mm,angle CJP23GB286ZN
CN102 nsp WAFER , 2.5MM ANGLE CJP07GB03ZY
CN103 nsp LOCK-WAFER/ANGLE/2MMPITCH/5PIN CJP05GJ288ZY
CN104 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/3PIN CJP03GI288ZY *
z
F1001 943652000620S FUSE(372Series/100mA/TR5) CBA2D0100A3EYT
FL101 943172100150S V.F.D(FUTABA,18-BT-02GINK) CFL18BT021GINK *
JK102 00D9430105204 JACK,HEADPHONE(SILVER) HJJ2D003Y
JK104 90M-YT004500R JACK,PHONES(6.35mm,SILVER) CJJ2E026Z
L1001 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L6007 nsp FERRITE , CHIP BEAD(60ohm, 1608) CLZ9R005Z
L6008 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
LUG11 nsp WIRE ASS'Y CWE8102100RV
LUG13 nsp WIRE ASS'Y CWE8102180RV
RC101 943262100140S SENSOR,REMOCON(37.9KHz) CRVHM238RT12 *

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
