Denon AVR-1513 Service Manual

117
Ref. No. Part No. Part Name Remarks Q'ty New
z
T2001 943101101210S TRANS,SUB(6.9V,65mA) E3 CLT5I022YU
z
T2001 943101101220S TRANS,SUB(6.9V,65mA) E2 CLT5I022YE
z
T2001 943101101200S TRANS,SUB(6.9V,65mA) E1C CLT5I022YH
ZD201 90M-HD302440R DIODE,ZENER,1/2W,4.7V CVDZJ4.7BT
ZD202 943202008160S DIODE,ZENER,1/2W,12V E3 CVDZJ12BT

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
