Denon AVR-1513 Service Manual

119
Ref. No. Part No. Part Name Remarks Q'ty New
D5601-5604 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5701 943203002640S DIODE,BRIDGE HVDGBJ806
D5703 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT
D5704 00D9430182609 DIODE,SWITCHING CVD1SS133MT
RESISTORS GROUP
R5101 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5102 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5103 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5104 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5105 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5106 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5107 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5108 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5109 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5110 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5111,5112 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5113 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5114 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5115,5116 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5117,5118 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5119-5122 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5123 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5124 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5125 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5126 943252100130S PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5127 00MGD05562160 RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5129 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5130,5131 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5132 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5201 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5202 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5203 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5204 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5205 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5206 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5207 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5208 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5209 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5210 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5211,5212 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5213 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T
R5214 00MGD05561160 RES,CARBON(1/5W,560ohm,J) CRD20TJ561T
R5215,5216 nsp RES,M-OXIDEFILM(1W/5.6Kohm) CRG1SANJ562RT
R5217,5218 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R5219-5222 943124500050S RES,M-OXIDEFILM(2W/0.47ohm) CRG2SANJR47RT
R5223 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5224 00MGD05274160 RES,CARBON(1/5W,270Kohm,J) CRD20TJ274T
R5225 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
z
R5226 943252100130S PTCTHEMISTORS,CHIP(95C) CRTB59641A0095 *
R5227 00MGD05562160 RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T
R5229 00MGD05153160 RES,CARBON(1/5W,15Kohm,J) CRD20TJ153T
R5230,5231 00MGD05223160 RES,CARBON(1/5W,22Kohm,J) CRD20TJ223T
R5232 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT
R5301 00MGD05104160 RES,CARBON(1/5W,100Kohm,J) CRD20TJ104T
R5302 00MGD05681160 RES,CARBON(1/5W,680ohm,J) CRD20TJ681T
R5303 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R5304 00MGD05183160 RES,CARBON(1/5W,18Kohm,J) CRD20TJ183T
R5305 00MGD05122160 RES,CARBON(1/5W,1.2Kohm,J) CRD20TJ122T
R5306 nsp RES,M-OXIDEFILM(1W/1.2Kohm) CRG1SANJ122RT
R5307 00MGD05221160 RES,CARBON(1/5W,220ohm,J) CRD20TJ221T
R5308 00MGD05474160 RES,CARBON(1/5W,470Kohm,J) CRD20TJ474T
R5309 00MGD05333160 RES,CARBON(1/5W,33Kohm,J) CRD20TJ333T
R5310 nsp RES,M-OXIDEFILM(1W/47ohm) CRG1SANJ470RT
R5311,5312 00MGD05224160 RES,CARBON(1/5W,220Kohm,J) CRD20TJ224T
R5313 00MGD05272160 RES,CARBON(1/5W,2.7Kohm,J) CRD20TJ272T

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
