Denon AVR-1513 Service Manual

67
BN501
13.DGND 12.MUTE_+B 11.RLY_GND 10.+12V 9.FR 8.AGND 7.SR 6.AGND 4.AGND 5.CEN 3.SL 2.AGND 1.FL
BN502
1.FRONT_RLY 2.C/S_RLY 3.H/P_RLY 4.ASO_DET 5.DC_PROT 6.THERMALDET_A 7.THERMALDET_B
CEN
FR SR SL FL
Q5703
Q5108Q5208Q5308Q5408Q5508
Q5705Q5708
Q5706
Q5704
Q5407 Q5107Q5207Q5307Q5507
Q5707
R5126R5226R5326R5426R5526
Q5701
C5620 C5619
C5618
C5617
C5616
Q5601 Q5603 Q5604 Q5602
MAIN
(FOIL SIDE)
181716151413121110987654321
M
L
K
J
I
H
G
F
E
D
C
B
A
鉛フリー半田
半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
