Denon AVR-1603/683 User Manual

12
AVR-1603/683
Pin
No.
Pin Name FunctionI/O
77 PWR DOWN I POWER DOWN DETECT
78 RDS CLK O TDA7330 CONTROL CLOCK
79 RDS DATA O TDA7330 CONTROL DATA
80 NC 
81 VIDEO MUTE O VIDEO MUTE
82 M32 INTREQ I/O MELODY32 CONTROL
83 VIDEO SEL1 O VIDEO SELECT1
84 VIDEO SEL2 O VIDEO SELECT2
85 REMOCON I REMOTE CONTROL SIGNAL INPUT
86 GND 
87 GND 
88 VSS 
89 VDD 
90 NC 
91 NC 
92 PLL DATA O PLL CONTROL
93 PLL CLK O PLL CONTROL
94 PLL DT IN O PLL CONTROL
95 TU MUTE O TUNER MUTE
96 STEREO I STEREO DETECT
97 TUNED I TUNED DETECT
98 PLL CE O PLL CONTROL
99 NC 
100 NC 
