AVR-1603/683

Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty

VOLTAGE SEL. P.W.B. ASS’Y

(for Asia, Hong Kong & Taiwan R.O.C. model only)

C962 963 9004 708 Ceramic chip 0.1uF/50V

C965 963 9004 708 Ceramic chip 0.1uF/50V

C966 963 9005 901 Electrolytic 470uF/10V

C967 963 9004 708 Ceramic chip 0.1uF/50V

OTHER PARTS GROUP Q'ty

CB803 963 0050 502 Chip emifil 1

CB805-810 963 0050 502 Chip emifil 6

CN801 963 0086 107 16P connector socket 1

CN802 963 0086 204 19P connector socket 1

CN803 963 0097 206 8P connector socket 1

JACK801 963 0052 500 Coaxial 1

L802 963 0050 803 Inductor 4.7uh 1

L805,806 963 0050 803 Inductor 4.7uh 2

L807 963 0050 900 Inductor 2.2uh 1

XTAL1 963 0095 101 Crystal 12.288MHz 1

OTHER PARTS GROUP (E1,G1H,G1T model only)

CP901 963 0061 203 5P connector base for E1,E1H,E1T 1

CP902 963 0059 309 3P wire for E1,E1H,E1T 1

CN105 963 0059 105 2P wire for E1,E1H,E1T 1

CN903 963 0058 805 2P wire for E1,E1H,E1T 1

F101 960 0142 602 Fuse 250V-T2.5A for E1,E1H,E1T 1

F101A 960 0005 804 Fuse clip for E1,E1H,E1T 1

F101B 960 0005 804 Fuse clip for E1,E1H,E1T 1

F102 963 0057 107 Fuse 250V-T6.3A for E1,E1H,E1T 1

F102A 960 0005 804 Fuse clip for E1,E1H,E1T 1

F102B 960 0005 804 Fuse clip for E1,E1H,E1T 1

F901 963 0044 709 Fuse 250V-T3.15A for E1,E1H,E1T 1

F901A 960 0005 804 Fuse clip for E1,E1H,E1T 1

F901B 960 0005 804 Fuse clip for E1,E1H,E1T 1

JK911 960 0143 203 AC outlet for E1,E1H,E1T 1

JK912 963 0056 904 Slide SW for E1,E1H,E1T 1

963 0051 103 Card spacer for E1,E1H,E1T 1

963 0044 602 P.C. supporter for E1,E1H,E1T 2
