AVR-1603/683
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks
Q'ty
Ref. No. Part No. Part Name Remarks
Q'ty
Note : The symbols in the column “Remarks” indicate the following destinations.
E3 : U.S.A. & Canada model E1 : Asia model
EU : U.S.A. model (AVR-683) E1C : China model
E2 : Europe model E1H : Hong Kong model
EK : U.K. model E1T : Taiwan R.O.C. model
EA : Australia model E1K : Korea model
963 0092 010 Main P.W.B. Total Ass'y for E3,EU 1
963 0092 023 for E2,EK,EA
963 0092 036 for E1,E1T,E1H
963 0092 049 for E1C
963 0092 052 for E1K
44 Main P.W.B. Sub Ass'y
50 Video P.W.B. Sub Ass'y
55
Video CNT P.W.B. Sub Ass'y
69 Outlet P.W.B. Sub Ass'y
for E2,E1,E1T,E1H,E1K
963 0092 117 CPU P.W.B. Total Ass'y for E3,EU 1
963 0092 120 for E2,EK,EA
963 0092 133 for E1,E1T,E1H
963 0092 146 for E1C
963 0092 159 for E1K
41 Front P.W.B. Sub Ass'y
46
Optical-In P.W.B. Sub Ass'y
53 CPU P.W.B. Sub Ass'y
70
Power-Sw P.W.B. Sub Ass'y
for E2,EK,EA,E1
E1C,E1T,E1H,E1K
963 0094 403
Voltage Sel P.W.B. Total Ass'y
for E1,E1T,E1H 1
73
Voltage Sel P.W.B. Sub Ass'y
963 0092 214 CNT P.W.B. Total Ass'y for E3,EU 1
963 0092 227 for E2,EK,EA
963 0092 230 for E1,E1T,E1H
963 0092 243 for E1C
963 0092 256 for E1K
42 Encoder P.W.B. Sub Ass'y
43
Head Phone P.W.B. Sub Ass'y
45 CNT P.W.B. Sub Ass'y
47 Tuner P.W.B. Sub Ass'y
51
Pre-Amp P.W.B. Sub Ass'y
52 S-Video P.W.B. Sub Ass'y
54
S-Video CNT P.W.B. Sub Ass'y
61 C-Video P.W.B. Sub Ass'y for E3,EU
963 0092 311
Input-Vol P.W.B. Total Ass'y
for E3,EU 1
963 0092 324 for E2,EK,EA
963 0092 337 for E1,E1T,E1H
963 0092 340 for E1C
963 0092 353 for E1K
48
Input-Vol P.W.B. Sub Ass'y
963 0092 418 DSP P.W.B. Total Ass'y for E3,EU 1
963 0092 421 for E2,EK,EA
963 0092 434 for E1,E1T,E1H
963 0092 447 for E1C
963 0092 450 for E1K
49 DSP P.W.B. Sub Ass'y
1 963 0093 019 Front Panel for E3 1
963 0093 022 Front Panel for EU 1
963 0093 035 Front Panel for E2,EK,EA 1
963 0093 048 Front Panel for E1,E1C,E1T,
E1H,E1K 1
2 963 0051 501 DENON Badge for black model 1
963 0051 514 DENON Badge for gold model 1
3 963 0093 116 Window
for E3,EU,E1,E1C,E1T,E1H,E1K
1
963 0093 129 Window for E2,EK,EA 1
4 963 0093 213 Volume Knob for black model 1
963 0093 200 Volume Knob for gold model 1
5 963 0093 310 Function Knob for black model 1
963 0093 307 Function Knob for gold model 1
6 963 0093 417 Select Knob for black model 1
963 0093 420 Select Knob for gold model 1
7 963 0093 514 Power Push Button for black model 1
963 0093 501 Power Push Button for gold model 1
8 963 0094 801 3key(A) Button 2
9 963 0098 205 6key Button 1
10 963 0094 610 3key(B) Button for black model 2
963 0094 607 3key(B) Button for gold model 2
11 963 0094 717 4key Button for black model 1
963 0094 704 4key Button for gold model 1
12 963 0098 302 RCA Cover for E2,EK,EA,E3,EU 1
13 960 0191 417 Lens LED 2
14 963 0092 900 Knob Spring 1
15 963 0098 108 Main Chassis 1
16 960 0183 904 Foot Ass'y 4
17 960 0184 107 Bracket Supporter 1
18 960 0003 301 Supporter P.W.B. 2
19 963 0051 103 Card Spacer 2
20 960 0180 509
Display FLT 16-ST-42GNK
1
21 960 0181 100 Remocon Module 1
22 960 0197 204 LED HL50RDRF4T 8
24
Main Heat Sink for E3,EU 1
Main Heat Sink for E2,EK,EA,E1,
E1C,E1T,E1H,E1K 1
25 960 0184 204 Heat Sink-B Bracket 1
26 960 0184 301 Heat Sink-F Bracket 1
27 963 0044 107 Transistor 2SB1560-Y for E3,EU 5
960 0090 107 Transistor 2SB1559Y for E2,EK,EA,E1,
E1C,E1T,E1H,E1K 5
28 963 0044 204 Transistor 2SD2390-Y for E3,EU 5
960 0090 000 Transistor 2SD2389Y for E2,EK,EA,E1,
E1C,E1T,E1H,E1K 5
29 963 0058 106 Transistor 2SD947F 5
30 963 0098 506 Power Trans for E3,EU 1
963 0098 409 Power Trans for E2,EK,EA 1
963 0098 412 Power Trans for E1,E1T,E1H 1
963 0098 425 Power Trans for E1K,E1C 1
31 960 0184 000 Bracket Screw 2
32 960 0181 508 AC Outlet(2P) for E3,EU 1
960 0143 203 AC Outlet
for E2,EK,EA,E1,E1T,E1H
1
960 0144 202 AC Outlet for E1K 1
33 960 0194 809 2P Pin Jack 1
