AVR-1603/683
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks
SW901 960 0176 209 Push SW for E3,EU 1
T401 960 0186 600 If MW coil PCFMAF-270 1
T402 960 0007 349 If FM coil M292MEA-K5611FKG 1
T403 960 0007 352 If FM coil 292MEA-K5612X 1
T404 960 0071 207 MPX filter for E2,EK,EA 1
T405 960 0071 207 MPX filter for E2,EK,EA 1
T406 960 0037 607 Antibirdie filter for E2,EK,EA 1
VEC303 963 0095 208 Encoder SW 1
X401 963 0099 107 Crystal 7.2MHz 1
X402 963 0043 302 Ceramic resonator CSB456F11 1
963 0052 403 3P antenna terminal 1
963 0099 204 3P pin jack for E3,EU 1
960 0181 304 3P S terminal 1
960 0181 401 4P S terminal 1
960 0188 307 6P pin jack 1
960 0188 404 6P pin jack 1
960 0184 000 Bracket 4
963 0054 003 Tuner pack shield 1
963 0099 000 Earth “D”plate 1
INPUT VOLUME P.W.B. ASS'Y
SEMICONDUCTORS GROUP
IC701 963 0096 401 IC BD3811K1
IC721 963 0024 004 IC NJM2068M
IC761 963 0024 004 IC NJM2068M
IC762 963 0024 004 IC NJM2068M
IC763 963 0024 004 IC NJM2068M
IC781 963 0024 004 IC NJM2068M
IC782 963 0024 004 IC NJM2068M
IC783 963 0024 004 IC NJM2068M
Q751 963 0075 503 Transistor DTC144ES
Q752 963 0075 503 Transistor DTA114ES
Q753 960 0196 807 Transistor 2SK117Y
Q754 960 0196 807 Transistor 2SK117Y
Q755 963 0075 503 Transistor DTC144ES
Q756 963 0075 309 Transistor DTA114ES
Q757 960 0196 807 Transistor 2SK117Y
Q758 960 0196 807 Transistor 2SK117Y
Q771 963 0075 503 Transistor DTC144ES
Q772 963 0075 309 Transistor DTA114ES
Q773 960 0196 807 Transistor 2SK117Y
Q774 960 0196 807 Transistor 2SK117Y
D751 963 0096 605 Diode 1N4148WS
D752 963 0096 605 Diode 1N4148WS
D753 963 0096 605 Diode 1N4148WS
D754 963 0096 605 Diode 1N4148WS
D771 963 0096 605 Diode 1N4148WS
D772 963 0096 605 Diode 1N4148WS
ZD701 960 0222 603 Zener diode MTZJ7.5A
ZD702 960 0222 603 Zener diode MTZJ7.5A
RESISTORS GROUP
R701L 963 9004 339 Carbon chip 470 ohm 1/16W
R701R 963 9004 339 Carbon chip 470 ohm 1/16W
R702L 963 9004 339 Carbon chip 470 ohm 1/16W
R702R 963 9004 339 Carbon chip 470 ohm 1/16W
R703L 963 9004 339 Carbon chip 470 ohm 1/16W
R703R 963 9004 339 Carbon chip 470 ohm 1/16W
R704L 963 9004 339 Carbon chip 470 ohm 1/16W
R704R 963 9004 339 Carbon chip 470 ohm 1/16W
R705L 963 9004 339 Carbon chip 470 ohm 1/16W
R705R 963 9004 339 Carbon chip 470 ohm 1/16W
R706L 963 9004 339 Carbon chip 470 ohm 1/16W
R706R 963 9004 339 Carbon chip 470 ohm 1/16W
R707L 963 9004 339 Carbon chip 470 ohm 1/16W
R707R 963 9004 339 Carbon chip 470 ohm 1/16W
R708L 963 9004 339 Carbon chip 470 ohm 1/16W
R708R 963 9004 339 Carbon chip 470 ohm 1/16W
R711L 963 9004 245 Carbon chip 2.2 Mohm 1/16W
R711R 963 9004 245 Carbon chip 2.2 Mohm 1/16W
