AVR-1603/683
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
C506SL 963 9005 312 Electrolytic 100uF/10V
C506SR 963 9005 312 Electrolytic 100uF/10V
C507C 963 9003 194 Mylar film 0.0022uF/100V
C507FL 963 9003 194 Mylar film 0.0022uF/100V
C507FR 963 9003 194 Mylar film 0.0022uF/100V
C507SL 963 9003 194 Mylar film 0.0022uF/100V
C507SR 963 9003 194 Mylar film 0.0022uF/100V
C551 963 9005 846 Electrolytic 2.2uF/50V
C551M 963 9005 817 Electrolytic 100uF/35V
C551S 963 9004 562 Ceramic 0.047uF/50V
C552 963 9005 927 Electrolytic 0.1uF/50V
C553 963 9005 927 Electrolytic 0.1uF/50V
C554 963 9005 927 Electrolytic 0.1uF/50V
C555 963 9004 546 Ceramic 0.01uF/16V
C556 963 9004 546 Ceramic 0.01uF/16V
C557 963 9005 752 Electrolytic 10uF/35V
C621 963 9005 309 Electrolytic 47uF/10V
C622 963 9005 309 Electrolytic 47uF/10V
C623 963 9005 309 Electrolytic 47uF/10V
C624 963 9005 891 Electrolytic 470uF/6.3V
C625 963 9005 891 Electrolytic 470uF/6.3V
C626 963 9005 309 Electrolytic 47uF/10V
C627 963 9005 309 Electrolytic 47uF/10V
C628 963 9005 309 Electrolytic 47uF/10V
C629 963 9005 891 Electrolytic 470uF/6.3V
C630 963 9005 891 Electrolytic 470uF/6.3V
C631 963 9005 794 Electrolytic 100uF/16V
C632 963 9004 753 Ceramic chip 0.047uF/50V
C633 963 9004 753 Ceramic chip 0.047uF/50V
C634 963 9005 749 Electrolytic 1uF/50V
C635 963 9005 749 Electrolytic 1uF/50V
C651 963 9005 914 Electrolytic 4.7uF/50V
C652 963 9005 914 Electrolytic 4.7uF/50V
C653 963 9005 914 Electrolytic 4.7uF/50V
C654 963 9005 914 Electrolytic 4.7uF/50V
C655 963 9005 914 Electrolytic 4.7uF/50V
C656 963 9005 914 Electrolytic 4.7uF/50V
C657 963 9005 969 Electrolytic 4700uF/6.3V
C658 963 9005 891 Electrolytic 470uF/6.3V
C659 963 9005 891 Electrolytic 470uF/6.3V
C660 963 9005 312 Electrolytic 100uF/10V
C661 963 9005 312 Electrolytic 100uF/10V
C662 963 9005 312 Electrolytic 100uF/10V
C671 963 9005 749 Electrolytic 1uF/50V
C672 963 9005 749 Electrolytic 1uF/50V
C673 963 9003 108 Ceramic 0.022uF/25V
C674 963 9005 312 Electrolytic 100uF/10V
C681 963 9005 749 Electrolytic 1uF/50V
C682 963 9005 749 Electrolytic 1uF/50V
C683 963 9003 108 Ceramic 0.022uF/25V
C684 963 9005 312 Electrolytic 100uF/10V
C691 963 9005 749 Electrolytic 1uF/50V
C692 963 9005 749 Electrolytic 1uF/50V
C693 963 9003 108 Ceramic 0.022uF/25V
C694 963 9005 312 Electrolytic 100uF/10V
C901 963 9004 533 Ceramic 0.001uF/50V
C902 963 9004 533 Ceramic 0.001uF/50V
C903 963 9005 749 Electrolytic 1uF/50V
C904 963 9003 108 Ceramic 0.022uF/25V
OTHER PARTS GROUP Q'ty
CF401,402 960 0187 104 Ceramic filter for E3,EU 2
CF401,402 960 0177 509 Ceramic filter for E2,EK,EA 2
CF401 960 0187 104 Ceramic filter for E1,E1‚b,
E1K,E1H,E1T 1
CF402 960 0177 509 Ceramic filter for E1,E1‚b,
E1K,E1H,E1T 1
CF403 960 0187 609 Ceramic resonator 1
CN392 963 0087 300 3P wire 1
CN401 963 0085 409 10P connector socket 1
CN402 963 0097 303 15P connector socket 1
CN501 963 0085 506 9P connector socket 1
CN502-504 963 0085 603 5P connector socket 3
CN505 963 0085 700 6P connector socket 1
CN552 960 0239 900 13P connector socket 1
CN553 963 0085 409 10P connector socket 1
CN555 960 0239 900 13P connector socket 1
CN554 963 0097 002 13P wire 1
CN556 963 0086 709 11P connector socket 1
CN603 963 0085 603 5P connector socket 1
CN621 963 0085 603 5P connector socket 1
CN651 963 0085 603 5P connector socket for E3,EU 1
CN901 963 0090 902 3P wire 1
CP302 963 0075 600 6P connector base 1
CP392 963 0048 909 3P connector base 1
CP551 963 0097 701 12P connector base 1
CP554 963 0097 808 13P connector base 1
CP621 963 0086 903 5P connector base 1
CP651 963 0086 903 5P connector base for E3,EU 1
FE401 960 0187 706 Front end FTE4-401TB 1
G401  1P contact ass’y 1
G901  1P contact ass’y 1
JK901 963 0095 402 Head phone jack 1
L401 963 0052 102 Inductor 1uh 1
L402 960 0010 307 Inductor 10uh 1
L403 963 0056 409 If MW coil 1
