Denon AVR-1603/683 User Manual

33
AVR-1603/683
Ref. No. Part No. Part Name Remarks
R107FR 963 0047 900 Metal film 4.7 kohm 1W
R107SL 963 0047 900 Metal film 4.7 kohm 1W
R107SR 963 0047 900 Metal film 4.7 kohm 1W
R108C 963 9005 477 Metal oxide 0.22 ohm 1W
R108FL 963 9005 477 Metal oxide 0.22 ohm 1W
R108FR 963 9005 477 Metal oxide 0.22 ohm 1W
R108SL 963 9005 477 Metal oxide 0.22 ohm 1W
R108SR 963 9005 477 Metal oxide 0.22 ohm 1W
R109C 963 9005 477 Metal oxide 0.22 ohm 1W
R109FR 963 9005 477 Metal oxide 0.22 ohm 1W
R109FL 963 9005 477 Metal oxide 0.22 ohm 1W
R109SL 963 9005 477 Metal oxide 0.22 ohm 1W
R109SR 963 9005 477 Metal oxide 0.22 ohm 1W
R110C 963 9005 477 Metal oxide 0.22 ohm 1W
R110FR 963 9005 477 Metal oxide 0.22 ohm 1W
R110FL 963 9005 477 Metal oxide 0.22 ohm 1W
R110SL 963 9005 477 Metal oxide 0.22 ohm 1W
R110SR 963 9005 477 Metal oxide 0.22 ohm 1W
R111C 963 9005 477 Metal oxide 0.22 ohm 1W
R111FL 963 9005 477 Metal oxide 0.22 ohm 1W
R111FR 963 9005 477 Metal oxide 0.22 ohm 1W
R111SL 963 9005 477 Metal oxide 0.22 ohm 1W
R111SR 963 9005 477 Metal oxide 0.22 ohm 1W
R118C 963 9005 480 Metal oxide 10 ohm 1W
R118FL 963 9005 480 Metal oxide 10 ohm 1W
R118FR 963 9005 480 Metal oxide 10 ohm 1W
R118SL 963 9005 480 Metal oxide 10 ohm 1W
R118SR 963 9005 480 Metal oxide 10 ohm 1W
R119C 963 9005 480 Metal oxide 10 ohm 1W
R119FL 963 9005 480 Metal oxide 10 ohm 1W
R119FR 963 9005 480 Metal oxide 10 ohm 1W
R119SL 963 9005 480 Metal oxide 10 ohm 1W
R119SR 963 9005 480 Metal oxide 10 ohm 1W
R135 963 0045 203 Winding 0.1 ohm 5W
R136 963 0045 203 Winding 0.1 ohm 5W
R141 960 0180 606 Metal film 0.22 ohm 1W
R142 960 0180 606 Metal film 0.22 ohm 1W
R148 960 0180 606 Metal film 0.22 ohm 1W
R149 960 0180 606 Metal film 0.22 ohm 1W
R151 963 9003 343 Metal film 68 ohm 1/4W
R154 963 0043 108 Metal film 2.2 Mohm 2W for E3,EU
R179 963 9003 055 Metal film 47 kohm 1/4W
R181 963 0047 900 Metal film 4.7 kohm 1W
R185 963 9005 655 Metal film 22 ohm 1/4W
VR101 960 0091 601 Semi fixed resistor 1kohm
VR102 960 0091 601 Semi fixed resistor 1kohm
VR103 960 0091 601 Semi fixed resistor 1kohm
VR104 960 0091 601 Semi fixed resistor 1kohm
VR105 960 0091 601 Semi fixed resistor 1kohm
Ref. No. Part No. Part Name Remarks
CAPACITORS GROUP
C101C 093 9005 888 Electrolytic 47uF/50V
C101FL 093 9005 888 Electrolytic 47uF/50V
C101FR 093 9005 888 Electrolytic 47uF/50V
C101SL 093 9005 888 Electrolytic 47uF/50V
C101SR 093 9005 888 Electrolytic 47uF/50V
C102C 963 9005 752 Electrolytic 10uF/35V
C102FL 963 9005 752 Electrolytic 10uF/35V
C102FR 963 9005 752 Electrolytic 10uF/35V
C102SL 963 9005 752 Electrolytic 10uF/35V
C102SR 963 9005 752 Electrolytic 10uF/35V
C103C 963 9003 084 Ceramic 100pF/500V
C103FL 963 9003 084 Ceramic 100pF/500V
C103FR 963 9003 084 Ceramic 100pF/500V
C103SL 963 9003 084 Ceramic 100pF/500V
C103SR 963 9003 084 Ceramic 100pF/500V
C104C 963 9003 084 Ceramic 100pF/500V
C104FL 963 9003 084 Ceramic 100pF/500V
C104FR 963 9003 084 Ceramic 100pF/500V
C104SL 963 9003 084 Ceramic 100pF/500V
C104SR 963 9003 084 Ceramic 100pF/500V
C105C 960 9003 108 Ceramic 0.022uF/25V
C105FL 960 9003 108 Ceramic 0.022uF/25V
C105FR 960 9003 108 Ceramic 0.022uF/25V
C105SL 960 9003 108 Ceramic 0.022uF/25V
C105SR 960 9003 108 Ceramic 0.022uF/25V
C107C 963 9003 097 Mylar film 0.1uF/250V
C107FL 963 9003 097 Mylar film 0.1uF/250V
C107FR 963 9003 097 Mylar film 0.1uF/250V
C107SL 963 9003 097 Mylar film 0.1uF/250V
C107SR 963 9003 097 Mylar film 0.1uF/250V
C131 963 9003 097 Mylar film 0.1uF/250V
C132 963 9003 097 Mylar film 0.1uF/250V
C133 963 9003 097 Mylar film 0.1uF/250V
C134 963 9003 097 Mylar film 0.1uF/250V
C135 963 9003 097 Mylar film 0.1uF/250V
C136 963 0087 203 Electrolytic 10000uF/63V
C137 963 0087 203 Electrolytic 10000uF/63V
C138 963 9005 749 Electrolytic 1uF/50V
C141 963 0021 900 Mylar film 0.047uF/100V
C142 963 0021 900 Mylar film 0.047uF/100V
C143 963 0021 900 Mylar film 0.047uF/100V
C144 963 9003 110 Electrolytic 4700uF/35V
C145 963 9003 123 Electrolytic 1000uF/35V
C146 963 9005 749 Electrolytic 1uF/50V
C148 963 9005 749 Electrolytic 1uF/50V
C150 963 0021 900 Mylar film 0.047uF/100V
C151 963 0021 900 Mylar film 0.047uF/100V
C152 963 0021 900 Mylar film 0.047uF/100V
C153 963 0021 104 Electrolytic 6800uF/16V
C154 963 9005 752 Electrolytic 10uF/35V
C155 963 0020 202 Ceramic 0.1uF/50V
