Denon AVR-1603/683 User Manual

37
AVR-1603/683
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks Q'ty
C262 963 9004 575 Ceramic chip 100pF/50V
C263 963 9004 575 Ceramic chip 100pF/50V
C264 963 9004 575 Ceramic chip 100pF/50V
C265 963 9004 575 Ceramic chip 100pF/50V
C266 963 9004 575 Ceramic chip 100pF/50V
C267 963 9004 575 Ceramic chip 100pF/50V
C271 963 9005 794 Electrolytic 100uF/16V
C272 963 9005 752 Electrolytic 10uF/35V
C301 963 9005 778 Electrolytic 10uF/50V
C302 963 9004 753 Ceramic chip 0.047uF/50V
C303 963 9005 309 Electrolytic 47uF/10V
C304 960 9003 108 Ceramic 0.022uF/25V
C305 963 9005 859 Electrolytic 47uF/16V
C306 963 9004 766 Mylar film 0.1uF/100V
C307 963 9005 749 Electrolytic 1uF/50V
C308 963 0021 900 Mylar film 0.047uF/100V
C309 963 0021 900 Mylar film 0.047uF/100V
C310 963 9005 749 Electrolytic 1uF/50V
C311 963 9005 406 Ceramic chip 30pF/50V
C312 963 9005 859 Electrolytic 47uF/16V
C313 963 9005 419 Mylar film 0.047uF/63V
C321 963 9004 685 Ceramic chip 1000pF/50V
C322 963 9004 575 Ceramic chip 100pF/50V
C324 963 9004 575 Ceramic chip 100pF/50V
C325 963 9004 575 Ceramic chip 100pF/50V
C331 963 9004 698 Ceramic chip 0.01uF/50V
C332 963 9004 698 Ceramic chip 0.01uF/50V
C335 963 9004 698 Ceramic chip 0.01uF/50V
C336 963 9004 698 Ceramic chip 0.01uF/50V
C381 963 9005 309 Electrolytic 47uF/10V
C382 963 9004 575 Ceramic chip 100pF/50V
C383 963 9004 575 Ceramic chip 100pF/50V
C384 963 9005 749 Electrolytic 1uF/50V
C385 963 9005 749 Electrolytic 1uF/50V
C386 963 9004 753 Ceramic chip 0.047uF/50V
C391 963 9004 591 Ceramic chip 22pF/50V
C392 963 9004 711 Ceramic chip 0.1uF/50V
C393 963 9005 859 Electrolytic 47uF/16V
C931 963 0076 104 Ceramic 0.047uF/250V(AC)
OTHER PARTS GROUP
BD201,202 963 0053 800 Beads inductor 2
CN201 963 0096 906 6P wire 1
CN202 963 0099 408 4P wire 1
CN302 963 0096 702 6P wire 1
CN931 963 0089 502 2P wire for E2,E1,G1C,G1H,
G1K,G1T,EK,EA 1
CP201 963 0097 604 6P connector base 1
CP202 963 0050 104 4P connector base 1
CP301A 963 0097 905 20P connector base 1
CP301B 960 0129 007 20P FFC connector base 1
CP303 963 0049 102 3P connector base 1
CP401 963 0088 008 10P connector base 1
CP402 963 0097 507 15P connector base 1
CP552 960 0239 609 13P connector base 1
CP553 963 0088 008 10P connector base 1
CP601 963 0087 805 11P connector base 1
CP701 963 0087 504 19P connector base 1
CP702 963 0087 902 17P connector base 1
CP703 963 0088 008 10P connector base 1
CP801 963 0087 407 16P connector base 1
CP802 963 0087 504 19P connector base 1
CP803 963 0097 400 8P connector base 1
FL301 960 0180 509 Fl 16-ST-42GNK 1
G301 963 0088 202 1P contact ass'y 1
JK301 963 0084 206 3P jack 1
L301 960 0128 008 Inductor 100uh 1
L302 960 0010 307 Inductor 10uh 1
L391 960 0215 908 Inductor 4.7uh 1
RMC301 960 0181 100 Remocon module 1
SW301B-309B 963 0095 305 Tact SW 9
SW301C-309C 963 0045 708 Tact SW 9
SW302A-304A 963 0095 305 Tact SW 3
SW305A 963 0045 708 Tact SW 1
SW931 963 0098 807 SW push for E2,E1,G1C,G1H,
G1K,G1T,EK,EA 1
VEC301,302 963 0095 208 Encoder SW 2
X201 960 0181 003 Ceramic resonator CST12.0MTW 1
X202 963 0099 505 Crystal 4.332MHz for E2,EK,EA 1
 Heat sink 1
963 0018 007 Screw 3x8 B-type ZNY/BH 1
960 0184 408 FLT holder 1
