44
AVR-1603/683
Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks
CAPACITORS GROUP
C701L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C701R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C702L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C702R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C703L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C703R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C704L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C704R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C705L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C705R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C706L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C706R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C707L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C707R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C708L 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C708R 963 9004 575 Ceramic chip 100pF/50V for E2,EK,EA
C711L 963 9004 698 Ceramic chip 0.01uF/50V
C711R 963 9004 698 Ceramic chip 0.01uF/50V
C713L 963 9005 765 Electrolytic 10uF/35V
C713R 963 9005 765 Electrolytic 10uF/35V
C714L 963 9003 152 Mylar film 0.068uF/100V
C714R 963 9003 152 Mylar film 0.068uF/100V
C715L 963 9003 152 Mylar film 0.068uF/100V
C715R 963 9003 152 Mylar film 0.068uF/100V
C716L 963 9005 765 Electrolytic 10uF/35V
C716R 963 9005 765 Electrolytic 10uF/35V
C721 963 9005 875 Electrolytic 47uF/25V
C722 960 9004 602 Ceramic 0.047uF/50V
C723 963 9005 875 Electrolytic 47uF/25V
C724 960 9004 602 Ceramic 0.047uF/50V
C725 963 9005 736 Mylar film 0.0047uF/100V
C726 963 9005 736 Mylar film 0.0047uF/100V
C727 963 9004 766 Mylar film 0.1uF/100V
C728 963 9004 766 Mylar film 0.1uF/100V
C729 963 9004 766 Mylar film 0.1uF/100V
C730 963 9004 766 Mylar film 0.1uF/100V
C731 963 9005 765 Electrolytic 10uF/35V
C732 963 9005 765 Electrolytic 10uF/35V
C733 963 9005 765 Electrolytic 10uF/35V
C734 963 9005 765 Electrolytic 10uF/35V
C735 963 9005 765 Electrolytic 10uF/35V
C736 963 9005 765 Electrolytic 10uF/35V
C741 963 9004 575 Ceramic chip 100pF/50V
C742 963 9004 575 Ceramic chip 100pF/50V
C743 963 9004 575 Ceramic chip 100pF/50V
C751 963 9005 749 Electrolytic 1uF/50V
C756 963 9005 749 Electrolytic 1uF/50V
C761FL 963 9004 753 Ceramic chip 0.047uF/50V
C761FR 963 9004 753 Ceramic chip 0.047uF/50V
C761SW 963 9004 753 Ceramic chip 0.047uF/50V
C762FL 963 9004 575 Ceramic chip 100pF/50V
C762FR 963 9004 575 Ceramic chip 100pF/50V
C762SW 963 9004 575 Ceramic chip 100pF/50V
C763FL 963 9004 753 Ceramic chip 0.047uF/50V
C763FR 963 9004 753 Ceramic chip 0.047uF/50V
C763SW 963 9004 753 Ceramic chip 0.047uF/50V
C764FL 963 9004 627 Ceramic chip 33pF/50V
C764FR 963 9004 627 Ceramic chip 33PF/50V
C764SW 963 9004 643 Ceramic chip 47pF/50V
C765FL 963 9005 765 Electrolytic 10uF/35V
C765FR 963 9005 765 Electrolytic 10uF/35V
C765SW 963 9005 765 Electrolytic 10uF/35V
C771 963 9005 875 Electrolytic 47uF/25V
C772 963 9005 875 Electrolytic 47uF/25V
C773 963 9005 749 Electrolytic 1uF/50V
C781C 963 9004 753 Ceramic chip 0.047uF/50V
C781FL 963 9004 753 Ceramic chip 0.047uF/50V
C781FR 963 9004 753 Ceramic chip 0.047uF/50V
C781SL 963 9004 753 Ceramic chip 0.047uF/50V
C781SR 963 9004 753 Ceramic chip 0.047uF/50V
C781SW 963 9004 753 Ceramic chip 0.047uF/50V
C782C 963 9005 914 Electrolytic 4.7uF/50V
C782FL 963 9005 765 Electrolytic 10uF/35V
C782FR 963 9005 765 Electrolytic 10uF/35V
C782SL 963 9005 765 Electrolytic 10uF/35V
C782SR 963 9005 765 Electrolytic 10uF/35V
C782SW 963 9005 914 Electrolytic 4.7uF/50V
C783C 963 9004 630 Ceramic chip 39pF/50V
C783FL 963 9004 669 Ceramic chip 56pF/50V
C783FR 963 9004 669 Ceramic chip 56pF/50V
C783SL 963 9004 630 Ceramic chip 39pF/50V
C783SR 963 9004 630 Ceramic chip 39pF/50V
C783SW 963 9004 575 Ceramic chip 100pF/50V
C786SW 963 9005 914 Electrolytic 4.7uF/50V
C791 963 9005 875 Electrolytic 47uF/25V
C792 963 9005 875 Electrolytic 47uF/25V
OTHER PARTS GROUP Q'ty
CN551 963 0096 809 12P shield wire 1
CN701 963 0086 204 19P connector socket 1
CN702 963 0085 302 17P connector socket 1
CN703 963 0085 409 10P connector socket 1
960 0188 200 4P pin jack 1
960 0188 307 6P pin jack 1
963 0094 102 Plate input 1
963 0094 005 Input cushion 1
