Denon AVR-1708 Service Manual

117
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E2 model
CP107 nsp CN.WAFER 3P L102526700300S
CP108 nsp CN.WAFER 17P L101100041710S
CP541 nsp CN.WAFER 3P L101220030000S
GND101 nsp TERMINAL EARTH 3790040886000S
JACK222 00D 963 0146 005 TER,RCA 1PIN G600107A0000YS
L101C 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101FL 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101FR 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101SL 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
L101SR 00D 963 0049 005 COIL INDUCTOR 0.5UH D330R50000000S
RLY541 00D 963 0218 506 RELAY BC3-24 24V 2A G680240202040S
TP101-105 nsp CN.WAFER 3P L101530140310S
JP108 00D 963 0223 009 R,THICK 0-J,1/16W C20000006M160S
JP350-352 00D 963 0223 009 R,THICK 0-J,1/16W C20000006M160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
