Denon AVR-1708 Service Manual

342
AVR-1708/1508/688/588/488 AVC-1508
PARTS LIST OF PACKING & ACCESSORIES d
＊本表に"nsp" と記載されている部品は供給できません。
＊ Partsforwhich"nsp"isindicatedonthistablecannotbesupplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
AVR1708E3 : U.S.A. & Canada model AVR1708E2 : Europe model AVR688E3 : U.S.A. & Canada model
AVR1508E3 : U.S.A. & Canada model AVR1508E2 : Europe model AVR1508EUT : Taiwan R.O.C. model
AVR588E3 : U.S.A. & Canada model AVR 488E3 : U.S.A. & Canada model
AVC1508JP : Japan model
Black : Black model
Premium Silver
: Premium Silver model
Silver
: Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
1 00D9630388908 INSTRUCTION MANUAL AVR1708E3 5707210120071S 1 *
1 00D9630389002 INSTRUCTION MANUAL AVR688E3 5707210120081S 1 *
1 00D9630389105 INSTRUCTION MANUAL AVR1708E2 5707210120091S 1 *
1 00D9630389208 INSTRUCTION MANUAL AVR1508E3 5707210120111S 1 *
1 00D9630389301 INSTRUCTION MANUAL AVR588E3 5707210120121S 1 *
1 00D9630389404 INSTRUCTION MANUAL AVR1508E2 5707210120131S 1 *
1 00D9630357300 INSTRUCTION MANUAL AVR1508EUT 5707210120140S 1 *
1 00D9630389507 INSTRUCTION MANUAL AVR1508JP 5707210120151S 1 *
1 00D9630389600 INSTRUCTION MANUAL AVR488E3 5707210120101S 1 *
2 nsp WARRANTY CARD E3 model 5777001610038S 1
2 nsp WARRANTY CARD NOTICE SHEET only AVC1508JP 5727001130021S 1
3 00D2310089007 AM LOOP ANTENNA for except AVC1508JP E605010110010S 1
4 nsp POLY BAG 6330000240000S 1
5 nsp S.S LIST 577700162001BS 1
5 nsp SVC STATION LIST only AVC1508JP 5777200040019S 1
6 00D9630158006 FM ANTENNA WIRE for except AVC1508JP E605010070001S 1
7 nsp SHEET(ASD1R) for except AVR1508EUT 5227000000340S 1
7 nsp SHEET(ASD1R) AVC1508JP 5227000000350S 1
8 nsp XM SHEET E3 model 5227000000200S 1 *
9 00D3991105008 REMOTE CONTROL RC-1075 E3 model 1 *
9 00D3991106007 REMOTE CONTROL RC-1076 E2 / EUT model 1 *
9 00D3991109004 REMOTE CONTROL RC-1079 AVR488E3 1 *
10 00D9630366809 REMOTE CONTROL RC-1085 AVR1708E3 8300107500010S 1 *
11 00D9630366902 CUSHION,SNOW 6230211924000S 1 *
12 00D9630241405 POLY BAG SET 6327040059000S 1
13 nsp BATTERY DRY G670001R50190S 2
14 nsp BATTERY DRY RC-1085 2
15 00D3210040006 MIC CONDESER DM-A405EM
AVR1708E3/AVR688E3/
AVR1708E2/AVR1508E2
1*
16 00D9630357609 BOX,GIFT AVR1708E3 6007211030060S 1 *
16 00D9630357702 BOX,GIFT AVR688E3 6007211030070S 1 *
16 00D9630357805 BOX,GIFT AVR1708E2 6007211030080S 1 *
16 00D9630357908 BOX,GIFT AVR1508E3 60072110300A0S 1 *
16 00D9630358004 BOX,GIFT AVR588E3 60072110300B0S 1 *
16 00D9630358107 BOX,GIFT AVR1508E2 60072110300C0S 1 *
16 00D9630358200 BOX,GIFT AVR1508EUT 60072110300E0S 1 *
16 00D9630358303 BOX,GIFT AVC1508JP 60072110300F0S 1 *
16 00D9630358406 BOX,GIFT AVR488E3 6007211030090S 1 *
17 nsp PAD FRONT 6240210474000S 1 *
18 nsp PAD BOX 6240210460000S 1 *
19 nsp UPC LABEL AVR1708E3 5507002370060S 1 *
19 nsp UPC LABEL AVR688E3 5507002370070S 1 *
19 nsp UPC LABEL AVR1708BKE2 5507002370080S 1 *
19 nsp UPC LABEL AVR1708SRE2 5507002370090S 1 *
19 nsp UPC LABEL AVR1508E3 5507002370110S 1 *

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
