Denon AVR-1708 Service Manual

119
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E2 model
C309,310 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C311 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C312 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C315 nsp C,CERAMIC 150PF-J/50V D010151167160S
C316,317 nsp C,CERAMIC 330PF-J/50V D010331167160S
C318 nsp C,CERAMIC 100PF-J/50V D010101167160S
C319,320 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C321,322 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C323-325 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C326 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C327,328 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C329 nsp C,FILM 0.1UF-J/100V D02010406C060S
C330 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C331 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C332 nsp C,CERAMIC 150PF-J/50V D010151167160S
C333 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C334 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C335 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C336 nsp C,CERAMIC 100PF-J/50V D010101167160S
C337 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C338 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C339 nsp C,CERAMIC 100PF-J/50V D010101167160S
C340 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C341,342 nsp C,CERAMIC 100PF-J/50V D010101167160S
C343 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C344,345 00D 963 0233 206 C,CERAMIC 0.001UF-K/50V D005102177530S
C346-349 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C350 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C351 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C352 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C353,354 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C355 nsp C,ELECT 470UF-M/63V D040471088010S
C356 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C357,358 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C541 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C541FL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C542 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C542FR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C543 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C543FL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C544 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C544FR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C545 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C545C 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C546 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C546SL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C547 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C547SR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C548 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C548SBL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C549 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C549SBR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
OTHERS PARTS GROUP
BD301-307 nsp COIL,BEAD MB-160808-0120H D340160800060S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
