Denon AVR-1708 Service Manual

126
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E2 model
CN505 nsp CN.WAFER 7P L101100030710S
CN506 nsp CN.WAFER 12P L101100031210S
CP501 nsp CN.WAFER 2CKT,YEL L108353280290S
CP503 nsp CN.WAFER 2CKT,RED L108353280280S
CP504 nsp CN.WAFER ST2P L108202000220S
CP505 nsp CN.WAFER 7P L101100040710S
CP506 nsp CN.WAFER 12P L101100041210S
CP511 nsp CN.WAFER 9P L101220090000S
CP512 nsp CN.WAFER 4P ANGLE L102526800400S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
CP514 CN.WAFER 13P L101220130000S
z F501 00D 963 0237 600 FUSE T2.5A /250V N751222501110S
F501A nsp HOLDER,FUSE CLIP G645000050010S
F501B nsp HOLDER,FUSE CLIP G645000050010S
z F503 00D 963 0104 704 FUSE T3.15A /250V N751223151110S
F503A nsp HOLDER,FUSE CLIP G645000050010S
F503B nsp HOLDER,FUSE CLIP G645000050010S
GND501 nsp TERMINAL EARTH 3790040886000S
RLY501 963682000640S RELAY HL3-1A-6SH G680060102020S
z SUB501 00D 963 0382 801 SUB TRANS 8200280150410S
nsp HEAT SINK 2120043538050S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH B020030081B10S
00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
nsp FUSE LABEL T4AL 250V 5507000001090S
z 00D 960 0143 203 SOCKET,POWER RECEPTA G435040110000S
Ref. No. Part No. Part Name Remarks Q'ty New
h

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
