Denon AVR-1708 Service Manual

133
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E2 model
CP804 nsp CN.WAFER 15P L100912150010S
CP805 nsp CN.WAFER 08P L100912080010S
CP1001 nsp CN.WAFER 8P L101100040810S
CP1002 nsp CN.WAFER 9P L101100040910S
JACK801 00D 963 0217 905 TER,RCA 2PIN G601206A0200YS
JACK802 00D 963 0294 601 JACK,D3.5 EARPHONE G40100350000YS
L801D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L802D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L803D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L805D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L806D nsp COIL INDUCTOR 22UH D330220010050S
L807D nsp COIL INDUCTOR 22UH D330220010050S
TP803 nsp CN.WAFER 8P L101220080000S
TP804 nsp CN.WAFER 4P L101220040000S
X801 00D 963 0217 701 RESONATOR,CERAMIC ZTT12.00MT E830120000060S
X802 00D 963 0217 604 CRYSTAL 4.332MHZ,HC-49U E800433200100S
OPT801D 00D 963 0237 503 MODULE JSR1165-C E100116500040S
OPT802D 00D 963 0237 503 MODULE JSR1165-C E100116500040S
nsp CN,WIRE 110MM/1P L000111010010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
