Denon AVR-1708 Service Manual

143
AVR-1708/1508/688/588/488 AVC-1508
AVR-688 E3 model
R104FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105 00D 963 0232 906 R,METAL FILM 47K-F,1/4W C060047343530S
R105C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105FL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R106C 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106FL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106FR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106SL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R106SR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107C 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107FL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107FR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107SL 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R107SR 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R108C 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R108FL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R108FR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R108SL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R108SR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R109C 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R109FL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R109FR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R109SL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R109SR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R110C 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R110FL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R110FR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R110SL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R110SR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R111C 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R111FL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R111FR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R111SL 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R111SR 00D 963 0345 903 R,FIXED 2WJ-0.47 N113136647820S
R117,118 00D 963 0144 502 R,CEMENT 0.1-J 5W C141R10069000S
R118C 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R118FL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R118FR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R118SL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R118SR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119C 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119FL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119FR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119SL 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R119SR 00D 963 9006 256 R,FIXED 1WJ-10 N113135610020S
R127C 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R127FL 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R127FR 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R127SL 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R127SR 00D 963 9005 642 R,METAL FILM 1.2K-J,1W C060012265050S
R132C 00D 960 9010 719 R,METAL FILM 47-J,1W C060047065060S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
