Denon AVR-1708 Service Manual

160
AVR-1708/1508/688/588/488 AVC-1508
AVR-688 E3 model
C752FR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C752SBL 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SBR 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SL 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SR 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SW 00D 963 0350 503 C,CERAMIC 390PF-J/50V D010391167160S
C753C 00D 963 0224 008 C,CERAMIC 470PF-J/50V D010471167160S
C753FL 00D 963 0223 902 C,CERAMIC 39PF-J/50V D010390167160S
C753FR 00D 963 0223 902 C,CERAMIC 39PF-J/50V D010390167160S
C753SBL 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SBR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SL 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SW 00D 963 0224 008 C,CERAMIC 470PF-J/50V D010471167160S
C755C nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755FL nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755FR nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SBL nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SBR nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SL nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SR nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SW nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C756C 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SBL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SBR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SW 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C757C nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757FL nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757FR nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757SBL nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757SBR nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757SL nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757SR nsp C,CERAMIC 10UF-Z/10V D011106592200S
C757SW nsp C,CERAMIC 10UF-Z/10V D011106592200S
C803 nsp C,CERAMIC 100PF-J/50V D010101167160S
C804,805 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C806 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C807,808 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C809 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C810 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C813 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C814-816 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C818 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C819 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C824,825 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C826-831 nsp C,CERAMIC 100PF-J/50V D010101167160S
C836,837 nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C865L nsp C,CERAMIC 120PF-J/50V D010121167160S
C865R nsp C,CERAMIC 120PF-J/50V D010121167160S
C871L 00D 963 0216 304 C,FILM 0.001UF-J/100V D02010206C060S
C871R 00D 963 0216 304 C,FILM 0.001UF-J/100V D02010206C060S
C916D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
