Denon AVR-1708 Service Manual

170
AVR-1708/1508/688/588/488 AVC-1508
AVR-688 E3 model
HDMI_PWR P.W.B. UNIT ASS'Y
C1198-1200 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1201,1202 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S
C1203-1206 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1207 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1208 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1209 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1210 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1211 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
OTHERS PARTS GROUP
BD1001-1003 nsp COIL,BEAD MB-160808 D340160800060S
CN406 nsp CN,WIRE 300MM/3P L000301030060S
CN1001 nsp CN.WAFER 8P L101100030810S
CN1002 nsp CN.WAFER 9P L101100030910S
CP514 nsp CN.WAFER 8P L101220080010S
JACK1001,1002 00D 963 0367 709 TER,RCA 6PIN G603610D0032YS
JACK1003 00D 963 0218 001 TER,RCA 2PIN G60122001000YS
JACK1004 00D 963 0218 108 TER,RCA 3PIN G60630401000YS
L1003-1006 nsp COIL INDUCTOR 22UH D330220010520S
X1011 00D 963 0294 407 CRYSTAL 28.63636MHZ E80028R636010S
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401H1 00D9630366500 IC KIA1117PI33 J126111733050S
CAPACITORS GROUP
C405H1 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C406H1 00D9630233303 C,CERAMIC 0.01UF-M/16V D005103773530S
OTHERS PARTS GROUP
CN404 nsp CN,WIRE 300MM/4P L000301040110S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
