Denon AVR-1708 Service Manual

172
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 E3 model
Q166-171 00D 960 0196 302 TR KTA1268BL J5001268B0050S
Q231 00D 960 0097 003 TR KRA104M J6000104M0010S
Q541 00D 963 0121 208 TR KRC107M J6020107M0010S
D101C 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101FL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101FR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101SL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D101SR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102C 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102FL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102FR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102SL 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D102SR 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D105C 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105FL 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105FR 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105SL 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D105SR 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D106,107 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D114,115 00D 960 0197 107 D,RECTIFIER BRIDGE KBPC604 K047604000020S
D139 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D140,141 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D142 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D143-152 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D153 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D154-157 00D 963 0020 309 D,SWITCHING 1SS133T K000013300520S
D231 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D541 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
ZD101 00D 963 0058 601 D,ZENER MTZJ12B K06012R044520S
ZD101C 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101FL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101FR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101SL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD101SR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R34P400S
ZD102C 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102FL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102FR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102SL 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD102SR 00D 963 0367 008 D,ZENER 0.2W 3.3V UDZ K06603R04P400S
ZD105 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
ZD231 00D 960 0095 704 D,ZENER MTZJ6.2B K06006R244520S
RESISTORS GROUP
R101 00D 963 0337 801 R,METAL FILM 100-J,2W C060010166520S
R103 00D 963 9005 639 R,METAL FILM 100-J,1W C060010165060S
R104 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
R104C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104FL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104FR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SL 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R104SR 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
R105 00D 963 0232 906 R,METAL FILM 47K-F,1/4W C060047343530S
R105C 00D 963 9006 285 R,FIXED 1WJ-5.6K N113135656220S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
