Denon AVR-1708 Service Manual

178
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 E3 model
C316,317 nsp C,CERAMIC 330PF-J/50V D010331167160S
C319,320 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C321,322 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
C324,325 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C326 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C327,328 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C329 nsp C,FILM 0.1UF-J/100V D02010406C060S
C330 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C333 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C334 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C339 nsp C,CERAMIC 100PF-J/50V D010101167160S
C340 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C341,342 nsp C,CERAMIC 100PF-J/50V D010101167160S
C343 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V D005104597530S
C344,345 00D 963 0233 206 C,CERAMIC 0.001UF-K/50V D005102177530S
C346-349 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C350 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C351 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C352 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C353,354 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C355 nsp C,ELECT 470UF-M/63V D040471088010S
C356 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C357,358 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C541 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C541FL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C542 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C542FR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C543 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C543FL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C544 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C544FR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C545 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C545C 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C546 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C546SL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C547 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C547SR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C548 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C548SBL 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
C549 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C549SBR 00D 963 0024 703 C,FILM 0.01UF-J/100V D02010306C060S
OTHERS PARTS GROUP
BD301-304 COIL,BEAD MB-160808 D340160800060S
CN102 nsp CN,WIRE 270,170MM/4P L000271040040S
CN301 nsp CN,WIRE 2P L000401020050S
CN303A nsp CN,WIRE 8P L000450080010S
CN304 nsp CN,WIRE 3P L000500030050S
CN305 nsp CN,WIRE 10P L000700100030S
CN541 nsp CN,WIRE 3P L000251030080S
CP101 nsp CN.WAFER 10P L102526701000S
CP103 nsp CN.WAFER 7P L101220070000S
CP105 nsp CN.WAFER 4P ANGLE L102526800400S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
