Denon AVR-1708 Service Manual

183
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 E3 model
POWER P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC501 00D 963 0057 806 IC KIA78R05PI J126780500370S
z IC502 00D 960 0195 808 IC ICP-N15 J120001500030S
IC515 00D 960 0174 900 IC KIA7815API J126781500000S
IC516 00D 963 0021 502 IC KIA7915PI J126791500030S
IC517 00D 960 0100 301 IC KIA7812API J126781200040S
Q501 00D 960 0196 409 TR 2SC1740SR J5021740S0010S
Q502 00D 963 0121 208 TR KRC107M J6020107M0010S
Q503 00D 960 0196 409 TR 2SC1740SR J5021740S0010S
D501-503 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
D504-507 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D508,509 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
D521,522 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
D523-526 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
ZD501 00D 960 0095 500 D,ZENER MTZJ5.1B K06005R144520S
ZD502 00D 963 0219 903 D,ZENER MTZJ16B K06016R044520S
RESISTORS GROUP
R506 00D 963 0244 305 R,METAL FILM 2.2M 0.5W C060022564520S
R507 00D 963 0232 809 R,METAL FILM 10-J,1/4W C060010063520S
R516-519 00D 963 0216 003 R,METAL FILM 0.22-J,1W C060R22065050S
R520 00D 963 0215 907 R,METAL FILM 4.7-J,1W C0604R7065050S
CAPACITORS GROUP
C501 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C502 00D 963 0217 002 C,ELECT 3300UF-M/16V D040332083010S
C503 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C504 00D 963 0323 802
C,CERAMIC AC(SAFETY) 0.0047UF
250VAC
D00847208H010S
C506 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C526,527 00D 960 0186 202 C,ELECT 220UF-M/35V D040221085050S
C528 00D 963 0324 908 C,ELECT 4700UF-M/35V D040472085020S
C529 00D 963 0224 707 C,ELECT 2200UF-M/35V D040222085020S
C530-532 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C534,535 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
OTHERS PARTS GROUP
BKT501 nsp SHIELD PLATE GND 3070045526010S
CLAMP102-105 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN505 nsp CN.WAFER 7P L101100030710S
CN506 nsp CN.WAFER 12P L101100031210S
CP501 nsp CN.WAFER 2CKT,YEL L108353280290S
CP503 nsp CN.WAFER 2CKT,RED L108353280280S
CP504 nsp CN.WAFER ST2P L108202000220S
CP505 nsp CN.WAFER 7P L101100040710S
CP506 nsp CN.WAFER 12P L101100041210S

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
