Denon AVR-1708 Service Manual

20
AVR-1708/1508/688/588/488 AVC-1508
2. Analog video
2.1. MONITOR OUT (CVBS) output NG
MONITOR OUT (CVBS) output NG
※ When checking operation, select
DVD for the function.
(COMPONENT1 input)
Checking the video convert ON/OFF settings
Video convert ON
Video convert OFF
Input
CVBS
Input
S
I n p u t
COMPONENT
Input
CVBS
Input
S
Input
COMPONENT
AB
Progressive
no output
A No output No output
2. アナログビデオ
2.1. MONITOROUT(CVBS)出力NG
MONITOROUT(CVBS)出力NG ※ 動作を確認する時はファンクショ
ンを DVD に選択してください。
(COMPONENT1入力 )
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON/OFFの設定確認
ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄON ﾋﾞﾃﾞｵｺﾝﾊﾞｰﾄOFF
入力
CVBS
入力
S
入力
COMPONENT
入力
CVBS
入力
S
入力
COMPONENT
Aへ Bへ
ﾌﾟﾛｸﾞﾚｯｼﾌﾞ
出力されません
Aへ 出力されません 出力されません
