Denon AVR-1708 Service Manual

234
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
CP301B 00D 963 0368 506 CN.FPC 35P L131103500010S
CP302 nsp CN.WAFER 3P ANGLE L102526803010S
CP304 nsp CN.WAFER 3P L101220030000S
CP305 nsp CN.WAFER 10P L101220100010S
CP306 nsp CN.WAFER 3P L101220030010S
G301 nsp RING,TER WIRE 120MM/1P 8410121010060S
G302 nsp RING,TER WIRE 120MM/1P 8410121010110S
G304 nsp RING,TER WIRE 70MM/1P 8410700010070S
JACK304 00D 963 0146 403 TER,RCA 3PIN
G606308HG110YS
JACK501,502
00D 963 0146 607 TER,BOARD SCREW 8P G614801A0200YS
JACK503 00D 963 0158 608 TER,BOARD SCREW 2P G611201A0200YS
JK302 00D 963 0294 708 JACK,D6.5 PHONE
G402PJ612AG0YS
L302 nsp COIL INDUCTOR 10UH D330100700520S
L303 nsp COIL INDUCTOR 100UH D330101001020S
RLY541 00D 963 0366 201 RELAY G5PA-28-MC 24V 5A G680240502030S
RLY543-546 00D 963 0366 201 RELAY G5PA-28-MC 24V 5A G680240502030S
RMC301 00D 963 0217 808 MODULE,REMOCON NJL34H380A E940343800010S
z SW301 00D 963 0145 802 SW,PUSH SDDL-005-S(C-UL) G000122006060S
SW301A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW301C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW302C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW303C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW304C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW305C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW306C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW307A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW307B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW307C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW308A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW308B 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW308C 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW309A 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
SW310 00D 963 0095 305 SW,TACT SKHV10910D01 G180040500010S
VEC203 00D 963 0300 401 SW,ENCODER EC11B20C2 G121112020000S
VEC301 00D 963 0095 305 SW,ENCODER EC16B24SO G121162400070S
VEC303 00D 963 0095 305 SW,ENCODER EC16B24SO G121162400070S
nsp HOLDER FLT 4320200026000S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
