Denon AVR-1708 Service Manual

246
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
L802D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L803D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L805D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L806D nsp COIL,FILTER-INDUCTOR 22UH D330220010520S
L807D nsp COIL,FILTER-INDUCTOR 22UH D330220010520S
TP803 nsp CN.WAFER 8P L101220080000S
TP804 nsp CN.WAFER 4P L101220040000S
X801 00D 963 0217 701 RESONATOR,CERAMIC ZTT12.00MT E830120000060S
OPT801D 00D 963 0237 503 MODULE JSR1165-C E100116500040S
OPT802D 00D 963 0237 503 MODULE JSR1165-C E100116500040S
nsp CN,WIRE 110MM/1P L000111010010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
