Denon AVR-1708 Service Manual

250
AVR-1708/1508/688/588/488 AVC-1508
AVR-1508 EUT model
VIDEO P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1301 00D 960 0175 200 IC BA7625 J171762500000S
IC1302,1303 00D 963 0083 304 IC BA7626 J171762600000S
IC1304 00D 960 0239 104 IC KIA7806API J126780600130S
IC1305-1307 00D 963 0148 401 IC LA7956 J171795600010S
Q1301-1303 00D 960 0005 105 TR KTA1266Y J5001266Y0050S
Q1304,1305 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q1306-1309 00D 963 0121 208 TR KRC107M J6020107M0010S
Q1310-1313 00D 960 0005 202 TR KTC3198Y J5023198Y0000S
Q1314-1317 00D 963 0121 208 TR KRC107M J6020107M0010S
D1301 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
D1302-1305 00D 276 0401 905 D,SWITCHING 1SS133T K000013300520S
D1306,1307 00D 963 0355 401 D,SWITCHING KDS4148U K005041480030S
CAPACITORS GROUP
C1301-1309 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C1310 00D 963 9005 969 C,ELECT 4700UF-M/6.3V D040472081000S
C1311,1312 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1313-1315 00D 963 0311 607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C1316-1321 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C1322 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1323 00D 963 0311 607 C,ELECT 100UF-M/10V (Pb Free) D040101082090S
C1324 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1326 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1328 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1329 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C1330 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1331-1339 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C1340-1345 00D 963 9005 901 C,ELECT 470UF-M/10V,6.3*11 D040471082060S
C1347 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1348 00D 960 9009 924 C,ELECT 100UF-M/16V D040101083070S
C1349,1350 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1351,1352 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
OTHERS PARTS GROUP
CN406 nsp CN,WIRE 300MM/3P L000301030060S
CN1301 nsp CN.WAFER 5P L101220050010S
CN1303 nsp CN.WAFER 8P L101100030810S
CP1302 nsp CN.WAFER 9P L101100030910S
JACK1301 00D 963 0218 001 TER,RCA 2PIN G60122001000YS
JACK1302 00D 963 0218 108 TER,RCA 3PIN G60630401000YS
JACK1303,1304 00D 963 0367 709 TER,RCA 6PIN G603610D0032YS
nsp HEAT SINK 2120044338010S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH B020030081B10S

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
