Denon AVR-1708 Service Manual

255
AVR-1708/1508/688/588/488 AVC-1508
AVR-588 E3 model
VR101SL 00D 960 0221 109 VR,SEMI CARBON EVN-DJAA03B C541102115000S
VR101SR 00D 960 0221 109 VR,SEMI CARBON EVN-DJAA03B C541102115000S
CAPACITORS GROUP
C101 00D 963 9005 804 C,ELECT 100UF-M/25V D040101084060S
C101C 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C101FL 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C101FR 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C101SL 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C101SR 00D 963 0234 506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C102 00D 963 0224 503 C,ELECT 22UF-M/50V D040220087060S
C102C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C102FL 00D 960 9010 133 C,ELECT 220UF-M/35V D040221085060S
C102FR 00D 960 9010 133 C,ELECT 220UF-M/35V D040221085060S
C102SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C102SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C103 00D 963 9006 557 C,ELECT 220UF-M/6.3V D040221081060S
C103C 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C103FL 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C103FR 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C103SL 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C103SR 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C104 00D 963 9006 557 C,ELECT 220UF-M/6.3V D040221081060S
C104C 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C104FL 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C104FR 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C104SL 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C104SR 00D 963 9003 084 C,CERAMIC 100PF-K/500V D00410106D050S
C105 00D 963 9006 557 C,ELECT 220UF-M/6.3V D040221081060S
C105C nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C105FL nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C105FR nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C105SL nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C105SR nsp C,CERAMIC 0.022UF-Z/50V D011223597160S
C106 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C107 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C107C 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107FL 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107FR 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107SL 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C107SR 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C108 00D 963 0149 400 CAP.E.GENERIC 10000UF/63V N211210388110S
C108C 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C108FL 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C108FR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C108SL 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C108SR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C109 00D 963 0149 400 CAP.E.GENERIC 10000UF/63V N211210388110S
C109C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C110 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C110C 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
