Denon AVR-1708 Service Manual

271
AVR-1708/1508/688/588/488 AVC-1508
AVR-588 E3 model
C917D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C918D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C921D nsp C,CERAMIC 100PF-J/50V D010101167160S
C923D nsp C,CERAMIC 22PF-J/50V D010220167160S
C924D nsp C,CERAMIC 22PF-J/50V D010220167160S
C927D 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C928D 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C931D nsp C,CERAMIC 100PF-J/50V D010101167160S
C932D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C933D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C934D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C935D 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C936D 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C937D nsp C,CERAMIC 1000PF-K/50V D011102777160S
C938D 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C939D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C940D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C941D 00D 963 0244 606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C950D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C951D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C952D 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C953D 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C954D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C955D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C956D nsp C,CERAMIC 22PF-J/50V D010220167160S
C957D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C959D nsp C,CERAMIC 22PF-J/50V D010220167160S
BC801 00D 254 4666 005 CE04W0H105ZC(FG) D041105090010S
OTHERS PARTS GROUP
BD802-809 nsp COIL,BEAD MB-160808 D340160800060S
BD809D nsp COIL,BEAD MB-160808 D340160800060S
BD810-817 nsp COIL,BEAD MB-160808 D340160800060S
CN106 nsp CN.WAFER 5P L101100030510S
CN108 00D 963 0085 302 CN.WAFER 17P L101100031710S
CP01 nsp CN.WAFER 16P L101100041610S
CP301A 00D 963 0367 400 CN.FPC 35P L131524923520S
CP701 nsp CN.WAFER 19P L101100041910S
CP702 nsp CN.WAFER 15P L100912150010S
CP703 nsp CN.WAFER 8P L101100040810S
CP801 00D 963 0149 303 CN.FPC 15P L131111500010S
CP802 nsp CN.WAFER 16P L100912160010S
CP803 nsp CN.WAFER 16P L101100041610S
CP804 nsp CN.WAFER 15P L100912150010S
CP805 nsp CN.WAFER 08P L100912080010S
CP1001 nsp CN.WAFER 08P L101100040810S
CP1002 nsp CN.WAFER 9P L101100040910S
JACK801 00D 963 0217 905 TER,RCA 2PIN G601206A0200YS
JACK802 00D 963 0294 601 JACK,D3.5 EARPHONE G40100350000YS
L801D nsp COIL INDUCTOR 4.7UH D3304R7000150S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
