Denon AVR-1708 Service Manual

293
AVR-1708/1508/688/588/488 AVC-1508
AVR-488 E3 model
2CH-POWER P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401D4 00D 960 0159 501 IC KIA7805API J126780500110S
IC401H 963603000090S CN,WIRE 80MM/3P L000800030160S
IC401X4 00D 963 0334 503 IC PQ20RX11 J126201100010S
IC402D4 00D 963 0226 608 IC KIA78R33PI J12678R330010S
IC402X4 00D 963 0366 603 IC KIA1117PI50 J126111750050S
IC403D4 00D 963 0366 706 IC KIA1117PI00 J126111700050S
Q401X4 00D 963 0120 801 TR KRC102S J522010200210S
Q402D4 00D 960 0097 304 TR KRC102M J6020102M0010S
Q402X4 00D 963 0120 801 TR KRC102S J522010200210S
Q409D4 00D 960 0097 304 TR KRC102M J6020102M0010S
D401H4 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D401X4 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402H4 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
D402X4 00D 963 0328 409 D,SWITCHING 1N4007 K000400700010S
ZD401D4 00D 960 0095 607 D,ZENER MTZJ5.6B K06005R644520S
RESISTORS GROUP
R401D4 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R401H4 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R401X4 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402D4 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402H4 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
R402X4 00D 963 9006 269 R,FIXED 1WJ-0.22 N113135622820S
CAPACITORS GROUP
C401D4 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C401H4 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C401X4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C402D4 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C402H4 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C402X4 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C403D4 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C403H4 00D 963 0021 900 C,FILM 0.047UF-J/100V D02047306C060S
C403X4 00D 960 0133 404 C,ELECT 10000UF 16V D040103083020S
C404D4 00D 960 0133 404 C,ELECT 10000UF 16V D040103083020S
C404H4 00D 963 0217 002 C,ELECT 3300UF-M/16V D040332083010S
C404X4 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C405D4 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C406D4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C406X4 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C407D4 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C407X4 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C408D4 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C408X4 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C409D4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C410D4 00D 963 0338 402 C,ELECT 330UF-M/6.3V D040331081050S
C411D4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C412D4 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C413D4 00D 963 0024 907 C,ELECT 1000UF-M/6.3V D040102081060S
