Denon AVR-1708 Service Manual

330
AVR-1708/1508/688/588/488 AVC-1508
AVC-1508 JP model
HDMI_PWR P.W.B. UNIT ASS'Y
JACK1307-1310 00D 204 6670 010 D-CONNECTOR L170001200010S
nsp HEAT SINK 2120044338010S
nsp
SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH B020030081B10S
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401H1 00D9630366500 IC KIA1117PI33 J126111733050S
CAPACITORS GROUP
C405H1 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C406H1 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V D005103773530S
OTHERS PARTS GROUP
CN404 nsp CN,WIRE 300MM/4P L000301040110S
CP513 nsp CN.WAFER 3P ANGLE L102526803010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
