Denon AVR-1708 Service Manual

86
AVR-1708/1508/688/588/488 AVC-1508
AVR-1708 E3 model
C108SR 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C109 00D 963 0149 400 CAP.E.GENERIC 10000UF/63V(M) N211210388110S
C109C 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109FL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109FR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109SL 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C109SR 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C110 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C110C 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C110FL 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C110FR 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C110SL 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C110SR 00D 963 0338 208 C,CERAMIC 470PF-K/500V D00447127D050S
C111 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C111C 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS *
C111FL 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS *
C111FR 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS *
C111SL 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS *
C111SR 00D 963 0367 101 C,CERAMIC 220PF-J/500V D00422106D05CS *
C112 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C112C 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C112SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C113C 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C113FL 00D 960 9010 133 C,ELECT 220UF-M/35V D040221085060S
C113FR 00D 960 9010 133 C,ELECT 220UF-M/35V D040221085060S
C113SL 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C113SR 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C114 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C114C 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114FL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114FR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114SL 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C114SR 00D 963 0216 100 C,CERAMIC 33PF-J/500V D00033006D050S
C115 00D 963 9003 097 C,FILM 0.1UF-K/250V D02010407H080S
C115SW 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C117-120 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C141SW1 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C142SW1 nsp C,CERAMIC 100PF-J/50V D010101167160S
C155 00D 963 0244 606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C161 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C162,163 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C164-167 nsp C,CERAMIC 100PF-J/50V D010101167160S
C168-172 00D 963 0244 606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C177 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C178,179 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C180,181 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C182 00D 963 0324 005 C,ELECT 100UF-M/100V D04010108C240S
C183 00D 963 0293 602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C190 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C221L nsp C,CERAMIC 100PF-J/50V D010101167160S
C221R nsp C,CERAMIC 100PF-J/50V D010101167160S
C222L 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C222R 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1708 Specifications

General

Speakers connectivity type	-
Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
Equalizer	Yes
HDMI version	1.3a
Product color	Black
Audio decoders	DTS, DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx
Apple docking compatibility	iPod
Optical drive included	No
HDMI in	2
Composite video in	4
S-Video inputs quantity	3
Headphone connectivity	6.3 mm
Number of HDMI outputs	1

Weight and Dimensions

Depth	383 mm
Width	434 mm
Height	171 mm
Weight	11100 g
