Denon AVR-1906 Service Manual

61
AVR-1906 / AVR-786 / AVC-1620
C823 00D 960 0298 802 C,ELECT 470UF-M/6.3V *
C824 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C825 nsp 00D 960 9010 010 C,ELECT 4.7UF-M/50V *
C830 00D 963 9005 901 C,ELECT 470UF-M/10V *
C832 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C833-834 nsp 00D 963 0233 905 C,CERAMIC 0.015UF-K/50V *
C835 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C836-837 nsp 00D 963 0224 105 C,CERAMIC 1000PF-K/50V
C838-841 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C842 nsp 00D 963 0129 608 C,CERAMIC 15PF-J/50V
C844-846 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C847 nsp 00D 963 0129 608 C,CERAMIC 15PF-J/50V
C848-857 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C858 nsp 00D 963 0224 202 C,CERAMIC 0.022UF-K/25V
C859 nsp 00D 963 0246 507 C,CERAMIC 0.068UF-K/50V
C860 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C861-862 nsp 00D 963 9005 998 C,CERAMIC 24PF-J/50V
C863 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C864-865 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C864L nsp 00D 963 9005 862 C,ELECT 47UF-M/16V *
C864R nsp 00D 963 9005 862 C,ELECT 47UF-M/16V *
C865L nsp 00D 963 9005 723 C,CERAMIC 120PF-J/50V *
C865R nsp 00D 963 9005 723 C,CERAMIC 120PF-J/50V *
C866-869 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C869L nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C869R nsp 00D 963 0223 601 C,CERAMIC 100PF-J/50V
C870-872 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C871L 00D 963 0216 304 C,FILM 0.001UF-J/100V *
C871R 00D 963 0216 304 C,FILM 0.001UF-J/100V *
C873-874 nsp 00D 963 9005 804 C,ELECT 100UF-M/25V *
C873C nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873FL nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873FR nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SBL nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SBR nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SL nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SR nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C873SW nsp 00D 963 9004 672 C,CERAMIC 680pF-J 50V
C874C nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874FL nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874FR nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874SBL nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874SBR nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874SL nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874SR nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C874SW nsp 00D 963 9006 146 C,CERAMIC 560PF-J/50V
C875-884 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C875C nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875FL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875FR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875SBL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875SBR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875SL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875SR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C875SW nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876C nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876FL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876FR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876SBL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876SBR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876SL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876SR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C876SW nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880C nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880FL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880FR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880SBL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
