Denon AVR-1906 Service Manual

62
AVR-1906 / AVR-786 / AVC-1620
C880SBR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880SL nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880SR nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C880SW nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C885 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C886 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C887 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C888 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C889-891 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C892 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C893 nsp 00D 963 9005 749 C,ELECT 1UF-M/50V
C894 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C895 00D 963 0216 508 C,FILM 0.12UF-J/63V *
C896 nsp 00D 963 9005 927 C,ELECT 0.1UF-M/50V *
C897-898 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C899 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C900 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C901 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C902 nsp 00D 963 9005 901 C,ELECT 470UF-M/10V *
C903 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C904 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C905-906 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C907 nsp 00D 960 9009 911 C,ELECT 100UF-M/10V *
C908 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C909 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C910 nsp 00D 963 9005 778 C,ELECT 10UF-M/50V *
C911 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C912-913 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C914-915 nsp 00D 963 9004 708 C,CERAMIC 0.1UF-K/50V *
C917 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C919 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
C921 nsp 00D 963 9004 698 C,CERAMIC 0.01UF-K/50V
OTHERS PARTS GROUP
CB801-806 nsp 00D 963 0050 502 BEAD,COIL HB-IT2012-121
CB810 nsp 00D 963 0050 502 BEAD,COIL HB-IT2012-121
CN801 nsp 00D 963 0086 301 CN.WAFER 18P
CN802 nsp 00D 963 0086 204 CN.WAFER 19P
CN803 nsp 00D 963 0110 701 CN.WAFER 14P
JACK801 00D 963 0217 905 TER,RCA 2PIN *
L801 nsp 00D 963 0050 803 COIL INDUCTOR 4.7UH-Q50/56M
L803-804 nsp 00D 963 0050 803 COIL INDUCTOR 4.7UH-Q50/56M
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-1906 Specifications

Power Amplifier Section

front power output (8 ohms)	85 W + 85 W
front power output (6 ohms)	120 W + 120 W
center power output (8 ohms)	85 W
center power output (6 ohms)	120 W
surround power output (8 ohms)	85 W + 85 W
surround power output (6 ohms)	120 W + 120 W
surround back power output (8 ohms)	85 W + 85 W
surround back power output (6 ohms)	120 W + 120 W

Preamplifier Section

input sensitivity/impedance	200 mV/47 kohms
output level/load impedance	SUBWOOFER 1.2 V/10 kohms
frequency response	10 Hz - 100 kHz (+1, -3 dB)
signal-to-noise ratio	98 dB (IHF-A weighted)
tone control treble	±12 dB at 10 kHz
tone control bass	±12 dB at 100 Hz

FM Section

tuning frequency range (FM)	87.5 - 107.9 MHz
usable sensitivity (FM)	1.0 µV (11.2 dBf)

AM Section

tuning frequency range (AM)	520 - 1710 kHz
usable sensitivity (AM)	18 µV

General

power supply	AC 120 V, 60 Hz
power consumption	5.1 A
dimensions	434 (W) x 147 (H) x 417 (D) mm
weight	11.7 kg
