157

PARTS LIST OF EXPLODED VIEW

Parts indicated by "nsp" on this table cannot be supplied.

P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.

Parts indicated by the "

★

" mark are not illustrated in the exploded view.

The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.

Note:

The symbols in the column "Remarks" indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model

EA : Australia model E1C : China model

BK : Black model SP : Premium Silver model

Ref. No. Part No. Part Name Remarks Q'ty New

1 nsp PCB FRONT ASSY E3,E2,EA COP12384B 1 *

1 nsp PCB FRONT ASSY E1C COP12384D 1 *

C1 - PCB V.AUX_VOL -

C2 - PCB HP -

C3 - PCB USB -

C4 - PCB FRONT -

C5 - PCB SELECTOR -

C6 - PCB HDMI FFC GUIDE -

C7 - PCB GUIDE R -

C8 - PCB GUIDE L -

C9 - PCB GUIDE TOP -

C10 - PCB 7CH_AMP ASSY E3,E2,EA COP12385G 1

C10 - PCB 7CH_AMP ASSY E1C COP12385I 1

2 nsp PCB CNT ASSY E3,E2,EA COP12387G 1 *

2 nsp PCB CNT ASSY E1C COP12387I 1 *

C11 - PCB FRONT CNT -

C12 - PCB SIDE CNT -

C13 - PCB RS232C -

3 nsp PCB MAIN ASSY E3 COP12386G 1 *

3 nsp PCB MAIN ASSY E2,EA COP12386H 1 *

3 nsp PCB MAIN ASSY E1C COP12386I 1 *

C14 - PCB SPK_PREOUT -

C15 - PCB RS232C CNT -

C16 - PCB FUSE -

4 nsp PCB INPUT ASSY E3,E2,EA COP12388G 1 *

4 nsp PCB INPUT ASSY E1C COP12388I 1 *

C18 - PCB INPUT -

C19 - PCB POSISTOR -

C20 nsp PCB VIDEO ASSY E3,E2,EA COP12389G 1 *

C20 nsp PCB VIDEO ASSY E1C COP12389I 1 *

C21 nsp PCB SMPS ASSY E3 COP12391B 1 *

C21 nsp PCB SMPS ASSY E2,EA COP12391C 1 *

C21 nsp PCB SMPS ASSY E1C COP12391D 1 *
