Denon AVR-2312 Service Manual

213
PCB VIDEO ASSY
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
EA : Australia model E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC551 235810046603S IC, AVDM2000 CVIAVDM2000
IC552 00D2622012908 IC, BU4052BCF CVIBU4052BCF
IC554 232810005504S IC, BD7628F CVIBD7628F
IC556 232810005504S IC, BD7628F CVIBD7628F
IC558 943239010400S REGULATOR IC NJM2845DL133 CVINJM2845DL133
D5101,5102 90M-HZ200190R DIODE, SWITCHING, SMD TYPE HVDRLS4148SR
D5104-5106 90M-HZ200190R DIODE, SWITCHING, SMD TYPE HVDRLS4148SR
D5108 90M-HZ200190R DIODE, SWITCHING, SMD TYPE HVDRLS4148SR
D5109 00D2760718902 DIODE, SCHOTTKY, 30V CVDRB521S-30
Q5101,5102 963212500030S T.R , ISA1530AC1 CVTISA1530AC1
Q5104 963212500030S T.R , ISA1530AC1 CVTISA1530AC1
Q5105,5106 943216500020S TR RT1N141C CVTRT1N141C
Q5108 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C
Q5109,5110 943216500020S TR RT1N141C CVTRT1N141C
Q5112 943216500020S TR RT1N141C CVTRT1N141C
RESISTORS GROUP
R5102-5108 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5110 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5112 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5118 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5120 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5122 nsp CHIP RES1%75OHM CRJ10DF75R0T
R51425143 nsp RES, CHIP(1608/1%/510ohm) CRJ10DF5100T
R5149,5150 nsp RES, CHIP(1608/1%/560ohm) CRJ10DF5600T
R51605161 nsp CHIP RES1%75OHM CRJ10DF75R0T
R52325234 nsp CHIP RES1%75OHM CRJ10DF75R0T
R52485249 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5269-5271 nsp CHIP RES1%75OHM CRJ10DF75R0T
R5301 nsp CHIP RES1%75OHM CRJ10DF75R0T
CAPACITORS GROUP
C5104 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5106 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5108 00D9430175108 ELECT CAP 10UF 50V CCEA1HH100T
C5114
nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5116 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5118 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5120 nsp CHIP CAP 10UF 6.3V CCUC0J106KC
C5122 nsp RES, CHIP(2012/5%/0ohm) CRJ18AJ0R0T
C5124 nsp CHIP CAP 10UF 6.3V CCUC0J106KC

Denon AVR-2312 Specifications

General

Impedance	8 Ω
Speaker selector	A+B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@8 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	6.3 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
Internet radio services supported	Last.fm, Napster
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Display	VFD
HDMI version	1.4a
Product color	Black
Audio decoders	Dolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume control	Rotary
Apple docking compatibility	iPad, iPhone, iPod
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W

Weight and Dimensions

Depth	382 mm
Width	434 mm
Height	167 mm
Weight	11000 g
